Wildix W24FXS Quick Installation Manual

W24FXS 2015 - Quick Installation Guide - English
Feb 10, 2020 11:58
W24FXS 2015 - Quick Installation Guide - English
W24FXS 2015 Quick Installation Guide explains the steps that help you to connect and configure the
FXS gateway. FXS gateway allows you to connect analog phones and fax machines to your IP PBX.
Updated: March 2017
Permalink: https://confluence.wildix.com/x/gwg8AQ

Overview and LED indications

Rj21 Wire Sequence (Pinout Chart)
Connection To Power Supply
Connection To The Network
Connection Of Analog Phones
Configuration Of The Fxs Gateway
Reset Of The Gateway
Control Calls Using Flash Button
Overview and LED indications
Rear panel
ON/OFF Switch
Power supply jack AC 110V~240V, 50-60Hz
RJ21 Port for patch panel connection
Front panel
1 WAN port RJ45 10/100 base-T
1 Console port RJ45 with RS232 standard to connect DB9
1 RST switch to perform the factory reset
1 PWR LED:
solid green indicates that the gateway is powered on
1 RUN LED:
turns solid green for a few seconds once the gateway is powered on;
fast blinking indicates that all ports are registered successfully
slow blinking indicates that ports failed to register
off (when connected to power) indicates that the gateway doesn't boot up
1-24 ports for connection of analog devices
1-24 LEDs:
solid green indicates that the port is in use
off (when connected to power) indicates that the port is idle
