Table of Contents 1 English, IHB - ELK 213 Disturbances in comfort Accessories General Technical data Component positions Electrical circuit diagram Pipe connections Electrical connection Index Activation of ELK 213 together with heat pump Immersion heater Table of Contents |...
ELK 213are made of stainless steel (SIS 2333), which gives a very good service life. ELK 213 is equipped with a time relay. Time delay is recommended according to the Swedish Power Asso- ciation standards when connected power exceeds 6...
Page 6
Reset overheat protection by pushing the but- overheat protection, thermostat and the im- ton. The fault must be rectified before doing this, mersion heater could be damaged. see section “Troubleshooting" on page 14. Chapter 1 | English, IHB - ELK 213 Immersion heater...
The safety valve must be "exercised" regularly, at least ELK 213 can be installed as a freestanding electric four times a year. boiler or as an electric heater with another heat source.
Page 8
System diagram Explanation Electric heater ELK 213 Pressure gauge See www.nibe.eu for complete docking prin- Expansion vessel ciples. Safety valve GP10 Circulation pump NOTE QM40 - QM41 Shut off valves This is the outline diagram. Actual installations QN11 Shunt valve...
Page 9
Installation alternative -FQ2 -FL2 Accumulator tank (SP 300) In the event of large hot water demands, ELK 213, in- stalled on double-jacket accumulator tank type, can -CM4 be used to heat the domestic hot water. This is also a -CP1 good solution for aggressive or hard water.
Page 10
Non-return valve Designations in component locations according to standard IEC 81346-1 and 81346-2. -BP5 -FL2 -EB1 -CM4 -EM1 -QM43 -GP4 -QN11 -QM44 -QM40 -QM41 -FL1 -GP10 -QM4 -RM1 -QM42 -FQ1 Chapter 1 | English, IHB - ELK 213 Immersion heater...
Page 11
Designations in component locations according to standard IEC 81346-1 and 81346-2. -BP5 -FL2 -EB1 -CM4 -EM1 -QM44 -GP4 -QN11 -QM45 -QM40 -QM41 -GP10 -QM4 -RM1 -QM43 -QM42 -FQ1 -FL1 -EB2 Immersion heater Chapter 1 | English, IHB - ELK 213...
The electrical circuit diagram is at the end of this In- staller handbook. ELK 213 must be installed via a circuit breaker, with a minimum breaking gap of 3mm. F1345 without 2.0 All electrical equipment is connected at the factory.
Page 13
F1345 with 2.0 SMO 20 and SMO 40 Terminal blocks X1 and X8 in ELK 213 connect to the AA7:X2 AA7:X2 terminal blocks X5, X7 and X8 on the input board AA101 in the heat pump as illustrated. -FC1 -AA101...
Page 14
Change-over occurs on terminal block (X8) using the wiring enclosed. Time relay ELK 213 is equipped with a time relay (KF1), which 7/9 kW in three steps blocks part of the electric heater via contactor (QA2) so that a maximum of 6 kW is connected the first two hours after the immersion heater has been disconnec- ted.
Sensors Activation of ELK 213 together with heat pump Overheat protection bulb The menu setting of ELK 213 can be performed via the start guide or directly in the menu system. Caution Also see the Installer manual for the product that ELK 213 will be connected to.
Disturbances in comfort Accessories Troubleshooting Thread flange kit For installing ELK 213 on SP 300. Part no. 022 077 In the event of malfunction or operating mal- function, first check the points below. NOTE Work behind covers secured by screws may only be carried out by, or under the supervision of, a qualified installation engineer.
