- Page 1 Quick Install Guide Tsunami QuickBridge.11-R Family Version 4.0 Part Number 73897 (Print version) Part Number 73895 (CD version)
- Page 2 Proxim Wireless Corporation. trademarks Proxim is a registered trademark, and Tsunami and the Proxim logo are trademarks, of Proxim Wireless Corporation. All other trademarks mentioned herein are the property of their respective owners.
-
Page 3: Table Of Contents
coNteNts Introduction ..............4 Package Contents ............5 Hardware and Software Installation ....... 7 Step 1: Plan for Installation ..............8 Step 2: Choose a Location ..............9 Step 3: Gather Required Tools .............. 10 Step 4: Unpack the Shipping Box ............10 Step 5: Determine Proper Mounting Orientation ........ -
Page 4: Introduction
Outdoor placement for significantly improved range and ease of installation ▪ Integrated antenna ▪ VLAN Support This document shows the basics of setting up the units. For detailed information, see the Installation and Management manual. Page 4 Copyright © 007 Proxim Wireless... -
Page 5: Package Contents
PacKage coNteNts Each QuickBridge.11 shipment includes the items in the following table. Verify that you have received all parts of the shipment. Note: Unless listed here, cables are not included with the unit. Units with integrated antennas (2 ea.) Installation CD (1 ea.) Power Injectors and Cords (2 ea.) 50 meter outdoor rated... - Page 6 Helical spring lock washer # 1/4 4 ea. Helical spring lock washer #5/16 2 ea Hex cap screw NC 5/16-18 x 80 4 ea. 68764, Screw, Machine, Pan, Phillips, 1/4”-20, 5/8”L Rubber Tape Strip (2 ea.) Page Copyright © 007 Proxim Wireless...
-
Page 7: Hardware And Software Installation
Hardware aNd soFtware iNstallatioN IMPORTANT! IMPORTANT! Before installing this product, see Safety and Regulatory Compliance Before installing this product, see Safety and Regulatory Compliance Information on the product CD for important information. Information on the product CD for important information. IMPORTANT! IMPORTANT! All units must be installed by a suitably trained professional installation All units must be installed by a suitably trained professional installation technician or by a qualified installation service. -
Page 8: Step 1: Plan For Installation
Required Transmission Line Types and Lengths Plan for: ▪ The unit’s continuous power consumption needs ▪ Lightning protection and system grounding ▪ Hardware mounting ▪ Cable installation including egress ▪ Pre-testing Equipment (back-to-back test procedure) Page Copyright © 007 Proxim Wireless... -
Page 9: Step 2: Choose A Location
To make optimal use of the unit, you must find a suitable location for the hardware. The range of the radio unit largely depends upon the position of the antenna. Proxim recommends you do a site survey, observing the following requirements, before mounting the hardware. -
Page 10: Step 3: Gather Required Tools
Note the Ethernet and MAC addresses of the unit, as well as the serial number; these addresses may be used when configuring the unit. Note: The serial number is required to obtain support from Proxim. Keep this information in a safe place. Page 10... -
Page 11: Step 5: Determine Proper Mounting Orientation
step 5: determine Proper Mounting orientation Locate the arrow on the back of the unit and determine your desired mounting orientation. For vertical polarization using the integrated antenna, the arrow should be pointing up (perpendicular to the ground). For horizontal polarization using the integral antenna, the arrow should be horizontal (parallel to the ground). -
Page 12: Step 6: Assemble Mounting Hardware
Attach the mounting bracket (C) to extension arm (B) with the screw, nut, and washers provided. Tighten the assembly (Torque 15 N∙m/130 in-lbs). The following figure shows the full assembly attached to the unit. Page 1 Copyright © 007 Proxim Wireless... - Page 13 Note that this figure is for illustration only. Units with integrated antennas must always be mounted in diagonal position to achieve vertical or horizontal polarization as indicated by the arrow on the back of the unit. Also, on units with direct-connected omni antennas, the enclosure must be mounted with the lower side in the horizontal position.
-
Page 14: Step 7: Perform Confidence Test (Optional)
When all tests have passed successfully, the wireless point-to-point bridge is ready to be installed. Proxim recommends that the BSU be installed at the location from where you expect the wireless network to be extended in the future. Page 14... -
Page 15: Step 8: Mount The Unit
step 8: Mount the unit To pole-mount the unit, insert the provided screws through bracket F. Fasten around the pole to bracket E and secure (Torque 11 N . m/100 in- lbs). To wall-mount the unit, mount bracket (E) to the wall using 4 screws (not provided), as shown: Note: At the end of the installation, the Ethernet and serial ports must be made... -
Page 16: Step 9: Plug In The Cables
RJ45 “Data In” port on the PoE adapter. To connect the unit directly to a PC, connect a cross-over Ethernet cable between the network interface card in the PC and the RJ45 “Data In” port on the power injector. Page 1 Copyright © 007 Proxim Wireless... -
Page 17: Step 10: Power On The Unit
step 10: Power on the unit The unit is equipped with a Power-over-Ethernet (PoE) module. Using PoE, you can provide electricity and wired connectivity to the unit over a single Category 5 cable. Although the power injector that is supplied with the unit is 802.3af- compatible, standard 802.3af-compliant power modules will not properly power the units. -
Page 18: Step 11: View Leds
Power is on; unit is self-heating. Flashing Green Wireless link is being Power is on; Ethernet link is established. down. Solid Green Wireless link has been being Power is on; Ethernet link is established. down. Page 1 Copyright © 007 Proxim Wireless... -
Page 19: Step 12: Align The Antenna
step 12: align the antenna Antenna alignment is a process to physically align the antenna of the radio receiver or transmitter for the best possible radio link between them. The units have an audible antenna alignment tool that can be activated by plugging in the serial dongle (supplied with every BSU) or by issuing the CLI command for antenna alignment (see “Antenna Alignment Commands”). -
Page 20: Step 13: Tighten The Cables
The lock nut (C) on the sealing cap/lock nut assembly (B) must be fully tightened over the RJ45 connector before the sealing nut (D) is fully tightened. Otherwise, the Ethernet cable may twist and damage. Page 0 Copyright © 007 Proxim Wireless... -
Page 21: Step 14: Weatherproof The Connectors
After you have fully assembled and tightened the cable, use the provided self-fusing, rubber-based tape strip and electrical tape (not provided; Proxim recommends Scotch™ Super 33+ Vinyl Electrical Tape) to seal the connection, as follows. Remove the film liner from the rubber-based tape strip, and stretch the tape until it is approximately half of its original width. -
Page 22: Step 15: Install Documentation And Software
Available from C:\Program Files\Tsunami\QuickBridge.11 [Model]: – Documentation (in Docs folder): See list above – Help files (in Help folder; click on index.htm to access) – MIB files (in MIBs folder) – TFTP Server (in Extras folder) Page Copyright © 007 Proxim Wireless... -
Page 23: Initialization
iNitializatioN Connecting to the unit requires either: ▪ A direct physical connection with an Ethernet cable or with a serial RS-232 cable ▪ A network connection Connecting with the Ethernet cable allows you to use of the Web Interface and SNMP in addition to the CLI. -
Page 24: Accessing The Web Browser
To use the CLI through the Ethernet port, you must have a telnet program, the CLI password, and the unit’s IP address. To access the unit through Ethernet on a Windows PC: Page 4 Copyright © 007 Proxim Wireless... - Page 25 You still need the CLI password of the unit. Proxim recommends you power off the radio and the computer before connecting or disconnecting the serial cable.
-
Page 26: Basic Configuration
Transmit Power Control is a manual configuration selection to reduce the output power in the radio. The maximum output power level for the operating frequency can be found in the event log of the unit embedded software. Page Copyright © 007 Proxim Wireless... - Page 27 ATPC (Automatic Transmit Power Control) is a feature to automatically adapt transmit power when the quality of the link is more than sufficient to maintain a good communication with reduced transmit power. This feature is required for FCC DFS. By default, the unit lets you transmit at the maximum output power that the unit can sustain for data rate and frequency selected.
-
Page 28: Ip Configuration
The VLAN Configuration page lets you change VLAN parameters; click Configure > VLAN. security settings Proxim highly recommends you change the security settings as soon as possible. To do so, click Configure > Interfaces > Wireless. The encryption key is set using the Security tab. -
Page 29: Upgrading Embedded Software
Proxim Web site. Note: Not all software releases support all Tsunami QB.11 products. Proxim recommends that you always refer to the Release Notes to determine whether the version of software to which you want to upgrade is supported on your product. -
Page 30: Default Settings
Kbps) Ethernet Configuration Auto-Speed/Auto-Duplex Serial Port Baud Rate 9600 SNMP Management Interface Enabled Telnet Management Interface Enabled HTTP Management Interface Enabled HTTP Port Telnet Port Telnet Login Timeout Telnet Session Timeout Password public Page 30 Copyright © 007 Proxim Wireless... - Page 31 Feature Default Maximum Satellites (per BSU) MAC Authentication Disabled Radius Authentication Disabled Encryption Disabled Static MAC Address Filter Disabled / No Entries Ethernet Protocol Filtering All Filters Disabled Announcement Period (when 100 ms roaming enabled) Multi-Frame Bursting Enabled Storm Threshold Broadcast/Multicast Unlimited Broadcast Protocol Filtering All Protocols Allowed...
-
Page 32: Technical Services And Support
If you are having trouble utilizing your Proxim product, please review the Installation and Management manual and the additional documentation provided with your product. If you require additional support, please refer to the “Technical Services and Support” chapter in the Installation and Management manual for details about the information you will need to gather before using the Support Options listed below.
