- Page 1 Patent(s) Pending Dell Computer and Monitor USFF Wall Mount Installation Instructions Kit P/N: 104-1965...
- Page 2 Kit Contents Wall Mount Hardware Package: Assembly Components: (4) Pan Head Screws (1) Main Bracket (4) Anchors Monitor Hardware Package: (8) Nylon Spacers (5) M4 x 10mm Flat Head Screws (5) M4 x 12mm Flat Head Screws (5) M4 x 20mm Flat Head Screws PC Wall Mount Installation Instructions Step 1.
- Page 3 Installation Instructions Step 4. Monitor Attachment: the four VESA mounting holes on the rear of the monitor. a. Determine if spacers are required: Some monitors have a "recess" on the rear options. b. Determine Screw Length: Only use the metric M4 screws provided. Screw length is determined by the spacers used (see Table A).
- Page 4 Installation Instructions Step 5. Computer Attachment: Slide computer into Main Bracket as shown. Step 6. Attach Mount Base: Attach base to wall using the 4 screws that were installed in 3b. Tighten Securely. Warranty Statement Innovation First, Inc. warrants our products against defects in material and workmanship for a period of one (1) year from the date of purchase.
