- Page 1 Rack Mount Monitor Tray with Keyboard Installation Instructions Kit P/N: 2UKVM-125 Kit P/N: 2UKVM-135...
- Page 2 Kit Contents (1) Partially Assembled Shelf w/Door (1) Mini Black Keyboard (PS2) Generic Monitor Hardware Bag: (1) Cable (PS2 to USB) 1/8" White Nylon Spacers (2) Rear Brackets 1/2" White Nylon Spacers (1) Cable Management Bracket Pan Head Screws M4x6mm (2) Cable Management Arms Pan Head Screws M4x25mm Pan Head Screws M4x30mm...
-
Page 3: Installation Instructions
Installation Instructions Step 4. Rear Bracket Attachment: Move the slide rails back approximately 10 inches. You may need to loosen the thumb screws to do this. Attach the Rear Rack Brackets and the Cable Arm Extension as shown below. Attach using (4) 8-32 x 3/8” Pan Head Screws and (4) 8-32 Nuts. The screws should be located in the slots as far apart from one another as possible (see below). - Page 4 Installation Instructions Step 5. Monitor Attachment: Turn the monitor face down on a large flat surface. Locate the four VESA mounting holes on the rear of the monitor. a. Determine if spacers are required: Some monitors have "recess" on the rear of the monitor.
- Page 5 Installation Instructions Table A Recess Depth Spacer Screw .125 (1/8) 12mm .250 (1/4) 14mm .375 (3/8) 18mm .500 (1/2) 25mm .625 (5/8) 25mm .750 (3/4) 30mm .875 (7/8) 30mm Screws and Spacers are Shown to Scale Page 5...
- Page 6 Installation Instructions Step 6. Attach Keyboard: Remove adhesive backing on (on bottom of and attach keyboard to shelf. Keyboard Step 7. Attach Cables: Route Keyboard Cable Through Square Hole Tie Strap Strap Tie Strap Tie Strap Monitor Cable (locations vary) Tie Strap Tie Strap Tie Strap...
- Page 7 Installation Instructions Monitor Mounting Guide Top of Monitor Hinge Page 7...
- Page 8 Warranty Statement Innovation First, Inc. warrants our products against defects in material and workmanship for a period of one (1) year from the date of purchase. Innovation First, Inc. liability shall be limited to repairing or replacing, at our option, any defective product. 245 289 465 530...
