Optional Accessories

To increase the enjoyment and utility of your Vizualogic
accessories are available from your local authorized distributor/retailer:
DVD PLAYER
• DVD/SVCD/CD/MP3 compatible
• PAL/NTSC color system
• Dolby Pro Logic surround
sound/DTS ready.
• Wireless remote control with
full functions.
• 7" (w) x 2" (h) x 7" (d)
(90-5008)
WIRELESS STEREO HEADPHONES
• 2-channel
• IR headphones
(90-3006)
THE GLOVE
TM
— AUTOMOTIVE DVD
AND VCR PROTECTIVE COVERS
• Mounts and Protects.
• Speeds Installation.
(89-2106-xx)
8
TM
System, several
Controls
A/V Controller:
- The Video Controller in your VL9000 kit is a 2 input/2 output controller.
- Connect a DVD player or VCR to Input 1, connect a second player to
Input 2.
- The system diagram below illustrates how to set up a 2 Input/2 Output
system for your vehicle. Each screen can independently display each of the
2 input source units.
- The Output RCA connectors (Audio R, Audio L, and Video) are linked to
the output connector for the headrest and can be used to supply signals to
audio devices such as FM Modulators and Headphone transmitters as well
as other screens.
Vizualogic
®
Headrest System Diagram
- See diagram insert or go to www.vizualogic.com.
