Optional Accessories

To increase the enjoyment and utility of your Vizualogic
accessories are available from your local authorized distributor/retailer:
DVD PLAYER
• DVD/SVCD/CD/MP3 compatible
• PAL/NTSC color system
• Dolby Pro Logic surround
sound/DTS ready.
• Wireless remote control with full functions.
• 7" (w) x 2" (h) x 7" (d)
(90-5008)
WIRELESS STEREO HEADPHONES
• 2-channel
• IR head phones
(90-3006)
THE GLOVE
TM
— AUTOMOTIVE DVD AND
VCR PROTECTIVE COVERS
• Mounts and Protects.
• Speeds Installation.
(89-2106-xx)
8
®
System, several
Controls
Monitor Controls:
up arrow: Increases each function in the menu.
down arrow: Decreases each function in the menu.
Menu: Switches through the functions in the menu to select the desired
screen adjustments.
Source: Selects input '1', 'A/V 1' or input '2', 'A/V 2'...
Power: Turn on or off the LCD monitor.
A/V Controller:
- The Video Controller in your VL9000 kit is a 2 input/2 output controller.
- Connect a DVD player or VCR to Input 1, connect a second player to
Input 2.
- The Slave 1 and Slave 2 RCA connectors (Audio R, Audio L, and Video) are
linked to the output connector for the headrest and can be used to supply
signals to audio devices such as FM Modulators and Headphone transmit-
ters as well as other screens.
Sub Menu:
Enter Sub Menu: Push and hold the Menu button:
IR Channel: Switches the IR transmitter between Off, A, or B channels
for the head phones.
Exit Sub Menu: Push the Menu button until it highlights the 'Exit' function.
Push the up button to exit out.
(continued)
5
