11
Insert a 10 cm connection cable and a 20 cm connection
cable into the ports of the power module.
10 cm
20 cm
12
Install the power module.
20 cm
10 cm
13
Connect the power module and
LED matrix.
1
Thread the connection
cable through the hole.
2
Insert the connection
cable into the LED
matrix.
