- Page 1 ER52000 Hardened PoE Switch FastFind Links Introduction User’s Guide Unpacking and Installation...
- Page 2 Disclaimer of Liability The information contained in this document is subject to change without notice. EtherWAN is not liable for any errors or omissions contained herein or for resulting damage in connection with the information provided in this manual.
-
Page 3: Changes In This Revision
This document assumes the reader has moderate hardware, computer, and Internet skills. Document Revision Level This section provides a history of the revision changes to this document. Revision Document Version Date Description Version 1 03/15/2016 Changes in this Revision This is first version of this document. ER52000 PoE Switch User Guide... -
Page 4: Document Conventions
Indicates a variable, which is a placeholder for actual text provided by the user or system. Italic font is also used to brackets indicate variables. [ ] square Indicates optional values. brackets { } braces Indicates required or expected values. | vertical bar Indicates that you have a choice between two or more options or arguments. ER52000 PoE Switch User Guide... -
Page 5: Table Of Contents
Connecting to the 10/100/1000 Mbps Port ............15 Checking the Installation ..................15 Applying DC Power ................... 15 Technology ......................16 Power ........................16 Mechanical ......................17 Interface ........................17 Environment ......................17 Regulatory Approvals ....................18 ER52000 PoE Switch User Guide... -
Page 6: Introduction
1 Introduction Topics: Congratulations on your purchase of the ER52000 Hardened PoE Switch from EtherWAN Systems, Inc. Your EtherWAN Hardened Key Features (page 7) PoE Switch is a state-of-the-art IEEE-compliant network solution Quick Start Guide (page 8) designed for users who require high-performance to eliminate bottlenecks and increase productivity. -
Page 7: Key Features
Key Features This section summarizes the key features of the ER52000 Hardened PoE Switch. Eight 10/100Base-TX Ethernet ports with M12 D-Coding Female 4-Pin Connector can connect to Power over Ethernet (PoE) devices Two 10/100/1000Base-TX Ethernet ports with M12 A-Coding Female 8-Pin Connector ... -
Page 8: Quick Start Guide
Wait for the Hardened PoE Switch to complete its Power On Self Test. Confirm that the LEDs for ports connected to a device are on. If not, replace the Ethernet cable, and then check the port LED again. ER52000 PoE Switch User Guide... -
Page 9: Unpacking And Installation
2 Unpacking and Installation Topics: This chapter describes how to unpack and install the ER52000 Hardened PoE Switch. Unpacking the Hardware (page 10) Hardware Features (page 10) Installing the Hardened Switch (page 13) ER52000 PoE Switch User Guide... -
Page 10: Unpacking The Hardware
One quick start guide If any item is damaged or missing, notify your authorized EtherWAN representative. Keep the carton, including the original packing material, in case you need to store the product or return Hardware Features The following sections describe the hardware features of the ER52000 Hardened PoE Switch. - Page 11 Figure 2-1. Front Panel of the ER52000 Hardened PoE Switch 10/100 Mbps Ports The ER52000 Hardened PoE Switch has 10/100 Mbps PoE ports (M12 D-Coding Female 4-Pin Connector) (see Figure 2-1). This port is auto-sensing, auto-MDIX 10/100 Mbps port. When you insert a cable into a 10/100 Mbps PoE port, the Hardened PoE Switch: Determines whether the cable is a straight-through or crossover cable.
-
Page 12: Front Panel
ON = valid network connection. OFF = no data transmission on port. Flashing = port is sending or receiving data. Front Panel The ER52000 front panel has a M12 S-Coding Male 4-Pin Connector for connecting the external power supply. ER52000 PoE Switch User Guide... -
Page 13: Installing The Hardened Poe Switch
Figure 2-2. Front Panel of the ER52000 Hardened PoE Switch Installing the Hardened PoE Switch Hardened PoE Switch installation involves the following steps: Preparing the site. See page 14 Installing the Hardened PoE . See page 14. Connecting to the 10/100 Mbps Port. -
Page 14: Preparing The Site
If installing the Hardened PoE Switch on a desktop or shelf, allow sufficient ventilation space between the device and the objects around it. ER52000 Hardened PoE Switch Dimensions: 140mm (W) x 65.8mm (D) x 228mm (H) (5.5” (W) x 2.59” (D) x 8.98” (H)) Connecting to the 10/100 Mbps Port The front panel of the Hardened PoE Switch provides 10/100 Mbps ports (see “10/100 Mbps... -
Page 15: Connecting To The 10/100/1000 Mbps Port
ON. The Hardened PoE Switch is now functional and ready to pass data. If the Power LED is not ON, check that the power source is plugged in correctly and that the power source is good. ER52000 PoE Switch User Guide... -
Page 16: Technology
Processing Type: Store-and-Forward Half-duplex back-pressure and IEEE802.3x full-duplex flow control Auto Negotiation Auto MDI/MDIX Power Specification Description Power Input: 110 VDC Power Consumption: 11.5 W Max. PoE Power Budget 120 W ER52000 PoE Switch User Guide... -
Page 17: Mechanical
Ethernet port: Link/Activity PoE port: PoE status Environment Specification Description Operating Temperature: -40°C to 75°C (-40°F to 167°F) Storage Temperature: -40°C to 85°C (-40°F to 185°F) Ambient Relative 5% to 95% (non-condensing) Humidity: ER52000 PoE Switch User Guide... -
Page 18: Regulatory Approvals
EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) Environmental Test IEC60068-2-6 Fc (Vibration) Compliance IEC60068-2-27 Ea (Shock) FED STD 101C Method 5007.1 (Free fall w/ package) Rail Traffic EN50155 ER52000 PoE Switch User Guide... - Page 19 TEL: +886 -2- 6629-8986 Email: info@etherwan.com.tw EtherWAN has made a good faith effort to ensure the accuracy of the information in this document and disclaims the implied warranties of merchantability and fitness for a particular purpose, and makes no express warranties, except as may be stated in its written agreement with and for its customers.
