Technical Information; Specifications - Command access VLP-UL-M-KIT Insert Instructions

TECHNICAL INFORMATION

• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or access control
units in-between power supply & module
Low Torque Mode
• Average Latch Retraction Current: 600 mA
• Average Holding Current: 150 mA
Standard Torque Mode
• Average Latch Retraction Current: 1 Amp
• Average Holding Current: 215 mA
High Torque Mode
• Average Latch Retraction Current: 2 Amp
• Average Holding Current: 250 mA
Select your preferred torque mode (ships in standard torque) Press the device push
Step 1
pad to the desired setting. (Recommend to fully depress and release 5%, giving the
device room for changing door conditions.)
While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 2
Continue to keep pad depressed, the device will beep 6 times. After the beeps have
Step 3
stopped, release the pad and now the adjustment is complete. If not to your liking
repeat the 3 steps.
Once you found the correct location, turn PTS switch to OFF position.
Step 4
B e
eePS xPlanation
Over Voltage
2 Beeps
Under Voltage
3 Beeps
4 Beeps Failed Sensor
5 Beeps Retraction or Dogging
failure
6 Beeps Push to Set
S P E C I F I C A T I O N S
**Important
Make sure to set PTS before finishing installation!
Setting PTS
t & D
rouBleShooting
> 30V unit will shut down. Check voltage & adjust to 24 V.
< 20V unit will shut down. Check voltage & adjust to 24 V.
Verify all 3 sensor wires are installed correctly. Replace sensor if problem
persists by contacting office.
Device physically binding during retraction or pulled from the dogged position.
1. After 1 fail: 5 beeps then immediately attempts to retract again.
st
2. After 2 fail: 5 beeps with pause in-between for 30 seconds then device
nd
attempts to retract again.
3. After 3 fail: 5 beeps every 7 minutes, device will not attempt to retract.
rd
To Reset: Depress bar for 5 seconds at any time.
Device is recording it's new position and power mode after the 6th beep.
MM4S S
witcheS
P
1 2
rogram
OFF Low Torque
ON
Standard Torque
OFF ON
ON ON High Torque
OFF OFF PTS programming locked
Info**
iagnoSticS
S
olution
Add Program
sticker to inside
of device
PTS Video
Click or Scan
