OM POWER OM2000+ Tuning Procedure And Part List page 6

Item No.
1 Analog meter FWD / REF
2 Band switch 8x3
3 Blower
4 Blower ebm-papst
5 Bridge
6 Bridge
7 Bridge
8 Capacitor ceramic
9 Cap ceramic disc
10 Cap ceramic disc
11 Cap ceramic disc
12 Cap ceramic disc
13 Capacitor ceramic
14 Capacitor ceramic
15 Capacitor ceramic
16 Capacitor ceramic
17 Capacitor ceramic
18 Capacitor ceramic
19 Capacitor ceramic
20 Capacitor ceramic
21 Capacitor ceramic
22 Capacitor ceramic
23 Capacitor ceramic
24 Capacitor ceramic
25 Capacitor ceramic
26 Capacitor ceramic
27 Capacitor ceramic
OM2000+ PARTS LIST
Description
70x70mm
8x3 position
24V 5,28W
230V 30W
KBU8J
B380C
DB157S
4n7 6kV
2n2 10kV
330 3,5kV
1n 12kV
470 16kV
1µF 50V
100pF 50V
100n 50V
100n 50V
100n 500V
100nF/1kV
10n 50V
10n / 1kV
10nF 500V
10nF / 1kV
10pF 500V
15pF 50V
1n /50V
1n 500V
1nF 50V
Exhibit 11
PE92252V1-000U
G2E085-AA01-01
8A 600V
0,8A 900V
1,5A 1000V
15,24mm
Φ 40mm
Φ 30mm
Φ 30mm
Φ 25mm
1206
1206
0805
1206
5mm
10mm
1206
5mm
5mm
10mm
1210
1206
0805
5mm
1206
Qty.
1
1
1
1
4
1
2
4
1
1
1
1
4
12
5
66
5
6
19
1
10
9
2
2
4
2
9
Page 6 of 12
