- Page 1 R5800 Voltage Current Simulator Instruction Manual REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
-
Page 2: Table Of Contents
Simulating Transmitter Output (XMT) ........... 11 Battery Replacement ................11-12 Fuse Replacement ................... 12 Accessories and Replacement Parts ............13 Product Care .................... 13 Product Warranty ..................13 Product Disposal and Recycling .............. 14 Product Support ..................14 REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 3: Introduction
Introduction Thank you for purchasing your REED R5800 Voltage/Current Simulator. Please read the following instructions carefully before using your instrument. By following the steps outlined in this manual your meter will provide years of reliable service. Product Quality This product has been manufactured to meet stated product specifications. -
Page 4: Features
20mA. When its voltage lies between 5.8V and 6.8V, the max load is 700Ω at 20mA. Note 2: Temperature coefficient: ±0.005% of the range per °C for the temperature ranges 5 to 18°C and 28 to 40°C. continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 5: Included
Operating Humidity Range: 0 to 85% Storage Temperature: 14 to 122°F (-10 to 50°C) Dimensions: 7.1 x 3.5 x 1.9" (180 x 90 x 47mm) Weight: 8.2oz (500g) Included • Test Leads • Alligator Clips • Protective Holster • Batteries REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 6: Instrument Description
Instrument Description R5800 Voltage/Current Simulator 1. LCD Screen 7. Unit mA/% Select Button 2. Unit V/mA Select Button 8. Zero/FS Points Select Button 3. Power Button 9. 25% Single Step Setting/Auto Ramp Button 4. Output ON/OFF Button 10. Output Terminals Output Value Setting Button... -
Page 7: Display Description
Indicates that the battery power is low and needs to be replaced Indicates that the output digits need to be set V. mA. % Indicates the current output value (unit of measure) Indicates that the output signal is on or off REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 8: Operating Instructions
Do not apply any voltage to the output terminal during the operation. If any improper voltage is applied to the output terminal, it will cause damage to the internal circuits. continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 9: Output Operation Procedure
Hold the button and the value will keep varying. Press the ON/OFF button to turn the output signal on and off as indicated by ON or OFF on the LCD display. continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 10: 25% Step Current Output
0% indicates 4mA and 100% indicates 20mA. Press the ON/OFF button turn the output signal on and off as indicated by ON or OFF on the display. Press the mA 100% button to exit the full scale current output set up. continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 11: Simulating Transmitter Output (Xmt)
Turn the power off the meter and remove any test leads that may be attached to the meter. Lift the tilt stand on the back of the unit to access the battery compartment door, which can be removed using a Phillips head screwdriver. Replace the 2 x "AA" batteries in the lid of the battery compartment. continued... REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 12: Fuse Replacement
Take off the protective boot (Figure 1), remove the four screws by using a standard-blade screwdriver, and then remove the cover (Figure 2). Replace the blown fuse(s). Reinstall the cover. Reinstall the meter's protective boot. REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com... -
Page 13: Accessories And Replacement Parts
REED Instruments guarantees this instrument to be free of defects in material or workmanship for a period of one (1) year from date of shipment. During the warranty period, REED Instruments will repair or replace, at no charge, products or parts of a product that proves to be defective because of improper material or workmanship, under normal use and maintenance. -
Page 14: Product Disposal And Recycling
Product Support If you have any questions on your product, please contact your authorized REED distributor or REED Instruments Customer Service by phone at 1-877-849-2127 or by email at info@reedinstruments.com. Please visit www.REEDINSTRUMENTS.com for the most up-to-date manuals, datasheets, product guides and software. - Page 15 TEST & MEaSuRE wITh ConfIdEnCE ChECk ouT ouR laTEST PRoduCTS! REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
- Page 16 REED Instruments 1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com...
