Summary of Contents for rollease acmeda KUMO

  • Page 1 KUMO Installation manual...
  • Page 3: Table Of Contents

    1.4 - Before starting installation page 3 2 - SAFETY page 4 2.1 - General safety information page 4 3 - KUMO COMPONENTS AND DIAGRAMS page 6 3.1 - Tilting diagrams page 6 4 - KUMO TECHNICAL SHEET page 7 4.1 - Tilting diagrams...
  • Page 4: Introduction

    1 – INTRODUCTION This “assembly manual” for KUMO awnings has been produced by ROLLEASE ACMEDA to supply the indications necessary for the operations of assembling the components that make up the product. Assembly must be carried out by personnel with suitable technical and professional qualifications, in accordance with the respective national laws or regulations (see Par.
  • Page 5: Assembly And Installation Equipment

    »»rawlplugs; »»spirit level; »»string. 1.3 - Before starting IMPORTANT Some components must be cut to suit the dimensions of the awning that is to be obtained (see Par. 3.3 “Table of cutting dimensions”). KUMO INSTALLATION – REV 00...
  • Page 6: Safety

    IMPORTANT ROLLEASE ACMEDA guarantees the EC marking only for products supplied by the company itself. If any parts have to be replaced with other components not guaranteed by ROLLEASE ACMEDA, the product guarantee will automatically become void and ROLLEASE ACMEDA shall not answer for any malfunctions of the product.
  • Page 7 If a ladder is required during installation, make sure that it is firmly placed on the ground in order to prevent it from tipping and causing serious injury to the people involved in installation operations. ATTENTION Make sure there are no people, animals and objects nearby when the awning opens and closes. KUMO INSTALLATION – REV 00...
  • Page 8: Kumo Components And Diagrams

    3 - KUMO COMPONENTS AND DIAGRAMS 3.1 Tilting diagrams Awning dimensions with arms folded Wall mounting Awning dimensions with arms folded Roof mounting KUMO INSTALLATION – REV 00...
  • Page 9: Kumo Technical Sheet

    4 - KUMO Technical sheet Fixing bracket KUMO INSTALLATION – REV 00...
  • Page 10: Intallation Kumo

    5 – Intallation Kumo Brackets position for Kumo on the wall Define the distance of the brackets and position them on the awning assembly frame. L is the with of the awning Use anchors M10, or at most M12 Brackets position for Kumo on the ceiling Define the distance of the brackets and position them on the awning assembly frame.
  • Page 11 Insert the plates ATTENTION: After attaching the brackets insert the plates in the slot in the supports Kumo for ceiling ATTENTION: For roof-mounted awnings, the support must be fitted vertically and the square nut inserted in the slot at the top KUMO INSTALLATION –...
  • Page 12 Kumo for wall Install the awning on the brackets fixed to the wall Kumo for wall ATTENTION: Block the awning with the screws KUMO INSTALLATION – REV 00...
  • Page 13 (Allen wrench 6) (see ref. 2). To decrease the inclination tighten the socket- head screw, raising the terminal bar. After regulation, check that the terminal bar is perfectly horizontal. ATTENTION: After regulation, firmly tighten the side screw 11 I KUMO INSTALLATION – REV 00...
  • Page 14 ATTENTION: With the awning almost closed, check that the arms are parallel to the cassette. Regulating the awning If they are not parallel, tighten or slacken the dowel in the lever (Allen wrench 3), accompanying the arm.
