- Page 1 KLIP & STEIN INSTALLATION MANUAL...
- Page 2 Information is supplied upon the condition that the persons receiving the information will make their own determination as to its suitability for their purposes prior to use. Rollease Acmeda assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein.
-
Page 3: Section 1 | Warranty
SECTION 1 | WARRANTY WARRANTY Rollease Acmeda provide a 5 year hardware warranty against defects to the original purchaser [the fabricator/manufacturer]. The hardware warranty is not to be transferred to the end consumer. The hardware warranty is limited to the repair or resupply of defective hardware components to the fabricator/manufacturer only. -
Page 4: Section 2 | Prior To Installation
• If you do not fully understand these instructions, contact Rollease Acmeda for clarification before installing • The Installer is responsible to ensure that all installation personnel have been adequately trained on the safe &... -
Page 5: Section 3 | Installation
SECTION 3 | INSTALLATION QUANTITY OF BRACKETS REQUIRED QUANTITY OF BRACKETS ACCORDING TO WIDTH AND PROJECTION Page 5 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda... - Page 6 Brackets must be positioned within the hatched areas; outer brackets must be at a minimum distance of 40mm from edge of the square bar (not red hatching) Page 6 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 7 The brackets must be positioned within the hatched areas BRACKET ALIGNMENT NOTE: • Ensure brackets are correctly aligned in all directions Page 7 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 8 INSTALL SQUARE BAR NOTE: • Locate the square bar into the mounting brackets SECURE SQUARE BAR WARNING: • DO NOT overtighten the fixing screws Page 8 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
-
Page 9: Check Operation
After checking that the awning is secure, cover the brackets with the caps CHECK OPERATION NOTE: • Open and close the awning to check correct operation Page 9 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda... - Page 10 While supporting the weight of the awning arms, tighten or loosen the grub screw [1] (3mm Allen Key) to adjust the arm alignment Tightening lifts the arm, loosening lowers the arm Page 10 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 11 In some cases, arms must be coupled with the arm support • Fit the arm on the lever by inserting the pin Page 11 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 12 Couple the tube with the supplied tube joiner kit FABRIC ASSEMBLY NOTE: • Slide the fabric into the tube, centre it, lock it and roll it up Page 12 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 13 Secure the latter to the roller support with the screws provided Page 13 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 14 Couple the terminal bar by inserting it on the pre-assembled joint and secure with the rivets provided • Fit the arm stoppers and the terminal bar connecting plates onto the terminal bar Page 14 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 15 Fix the arms to the terminal bar keeping them parallel to the square bar and tightening the M8x16 countersunk screws on the previously fitted plates • Remove the arm lock only after having fixed the terminal bar connecting screws Page 15 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 16 Fit the end caps onto the terminal bar • Adjust the awning as described previously in the non-coupled version; also adjust the angle of the centre bal- ance supports Page 16 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 17 Fit the brackets within the hatched areas; outer brackets at a minimum distance of 40mm from the edge of the square bar (not the red hatching) Page 17 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
-
Page 18: Arm Assembly
AWNING ADJUSTMENT NOTE: • Remove the arm support cap [1] rotating it downwards • Loosen the screw [2] (3mm Allen Key) Page 18 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda... - Page 19 After adjustment, secure by firmly tightening the screw [4] (3mm Allen Key) • Fit the cap [5] again, first by hooking it to the lower part, then clip in the top part Page 19 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
- Page 20 Once the proper position has been set, lock the screw [7] securing the dowel located on the upper part of the arm support (3mm Allen Key] • Always support the weight of the arms when adjusting the awning. Page 20 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
-
Page 21: Hood Assembly
NOTE: • Fit the hood onto the brackets, push it towards the wall and secure with M6 screws (5mm Allen Key) Page 21 KLIP & STEIN AWNING Product Spec Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda... - Page 22 Pre-assemble the M6 screw with the square nut, insert it into the cover slot, fit the covers and secure by tightening the M6 screw (5mm Allen Key) Page 22 KLIP & STEIN AWNING Installation Manual | v 1.0 2020 ©Copyright All Rights Reserved Rollease Acmeda...
