KUMO SYSTEM
ASSEMBLY MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the KUMO SYSTEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for rollease acmeda KUMO SYSTEM

Summary of Contents for rollease acmeda KUMO SYSTEM

  • Page 1 KUMO SYSTEM ASSEMBLY MANUAL...

  • Page 2: Table Of Contents

    Information is supplied upon the condition that the persons receiving the information will make their own determination as to its suitability for their purposes prior to use. Rollease Acmeda assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein.

  • Page 3: Section 1 | Warranty

    SECTION 1 | WARRANTY WARRANTY Rollease Acmeda provide a 5 year hardware warranty against defects to the original purchaser [the fabricator/manufacturer]. The hardware warranty is not to be transferred to the end consumer. The hardware warranty is limited to the repair or resupply of defective hardware components to the fabricator/manufacturer only.

  • Page 4: Section 2 | Guidelines

    To ensure the correct assembly of the entire system and for optimum operation of the finished product, it is necessary to be in possession of the following: • Awning assembly frame for testing & adjustment. • Complete set of tools. Page. 4 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 5: Section 3 | System Details

    5. Gear / Crank 11:1 6. 78mm Awning Tube 7. End Drive with Hole 8. Gear Drive End Cap 9. Pin Adaptor 10. Brush for Cassette Page. 5 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 6: Section 4 | Specifications

    2.0m 38.9 42.7 46.5 50.4 54.2 59.1 63.0 2.5m 43.7 47.6 51.4 55.2 60.1 64.0 3.0m 48.1 51.9 55.7 60.6 64.5 FABRIC EXCLUDED KUMO v1.00 Page. 6 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 7 5⁰ minimum inclination 65⁰ minimum inclination ROOF MOUNTING AWNING DIMENSIONS 600 cm 300 cm 264 mm 190mm 231mm 147mm 13⁰ minimum inclination 85⁰ minimum inclination Page. 7 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 8: Section 5 | Awning Assembly

    THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF AW02-0101-xxx000_KUMO_MountingBracketSpecs IN "MM" ITEM CODE: ROLLEASE ACMEDA. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE REV. WRITTEN PERMISSION OF ROLLEASE ACMEDA IS PROHIBITED. Page. 8 KUMO AWNING Assembly Manual | v 1.1...
  • Page 9 STEP 5 - PREPARE THE END BRACKETS Insert the nut (C) in the centre of the bracket and assemble the pin adaptor. Page. 9 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 10 Use straps to assist in keeping arms secure. IMPORTANT Ensure the correct arms are used for awnings over 5m widths. Refer BOM for codes. Page. 10 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 11 Fit the cover profile (N) onto the bottom profile (M), Insert the brush (K) in the cover profile (L). securing it with the screws. Now all screws can be tightened completely. Page. 11 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 12 Install the awning onto the brackets (S) fixed to the frame for testing & adjustment. Secure the awning with the screws provided (T) using Allen key 5mm. Page. 12 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 13 297mm for awnings greater than 5m wide. End cap STANDARD ARM (AWNINGS LESS THAN 5M WIDE) (AW91-0301-XXXLLL) End cap SPECIAL ARM (AWNINGS GREATER THAN 5M WIDE) (AW91-0302-XXXLLL) Page. 13 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
  • Page 14 • Complete 2-3 test cycles of opening/closing the awning. • Adjust any components that prevent the correct and unimpeded opening and closing movement of the awning. Page. 14 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 15: Section 6 | Adjusting The Awning

    If they are not parallel, tighten or slacken the dowel (C) in the lever using Allen wrench 3. Always support the weight of the arms and terminal bar when adjusting the arms. Page. 15 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...

  • Page 16: Section 7 | Removing And Packing The Awning

    During packing it is necessary to pay particular attention to the delicate parts of the awning (for example, the heads); these must be well protected with good packaging. Page. 16 KUMO AWNING Assembly Manual | v 1.1 ©Copyright All Rights Reserved Rollease Acmeda...
