peerless-AV ACC 845 Installation And Assembly

Installation and Assembly - Vibration Absorber Ceiling Mount for Unistrut
IMPORTANT! Read entire instruction sheet
before you start installation and assembly.
Before you start check the parts list below to
make sure all of the parts shown are included.
Parts List
Description
A anti- vibration mount
B rubber bumper
C plastic finishing caps
D adapter bracket for unistrut
E 5/16-18 x 1.25 socket bolt
F rubber grommet
G M5 x .8 x 10 mm socket-pin screw
H M5 x .8 x 10 mm phillips screw
I spring nut
Note: Actual parts may appear slightly different than illustrated.
• If mounting to wood, purchase model ACC 840. Model ACC 845 should be mounted to Unistrut
vibration mount is altered in any way it may not be as effective, or effective at all, in controlling vibration. In
addition, be certain that no part of the system, including any extension column that might be used, comes in
contact with the vibrating surface. If mounting through a drop ceiling, be sure to cut a large enough hole in the
ceiling tile as to avoid contact with the extension column. If using an escutcheon ring, be sure it does not come
in contact with the false ceiling. Also be sure to use the rubber bumpers (B) provided.
Visit the Peerless Web Site at www.peerlessindustries.com
• Installer must verify that the ceiling will safely support
four times the combined weight of all attached equip-
ment and hardware.
Qty. Part Number
055-0004
1
4 590-1124
2 590-1123
055-1175
2
2 520-1104
1 530-9401
520-1063
1
1 520-9250
2 560-2101
WARNING
1 of 4
WARNING
A
D
G
H
ISSUED:12-18-01 SHEET#: 055-9070-3 11-10-04
For customer service call 1-800-729-0307 or 708-865-8870.
Model:
®
ACC 845
B
C
F
E
I
®
only. If the anti-
