Ice And Water Dispenser - GE Monogram ZFSB27DASS Use And Care Manual

To use the
Press the rim of the glass gently against the
dispenser pad.
dispenser
Select CUBES
(on some models) or WATER
The spill shelf is not self-draining. To reduce
water spotting, the shelf and its grille should be
cleaned regularly.
If no water is dispensed when the refrigerator is
first installed, there may be air in the water line
system. Press the dispenser pad for at least two
minutes to remove trapped air from the water
line and to fill the water system. To flush out
impurities in the water line, throw away the
first six glassfuls of water.
A light switch (on some models) turns the
night light in the dispenser on or off. The light
also comes on when the dispenser pad is
pressed. The light in the dispenser should be
replaced with a 7-watt maximum bulb when it
burns out.
CAUTION: Never put fingers or any other
objects into the ice crusher discharge opening.
Ice storage
To remove:
bin
Lift the left corner to free the bin from the
shelf and pull the bin straight out while
supporting it at front and rear.
To replace:
Slide the bin back until the tab on the bin locks
into the slot on the shelf. If the bin does not go
all the way back, remove it and rotate the drive
mechanism 1/4 turn. Then push the bin back
again.
Ice & Water Dispenser
, CRUSHED ICE
.
(on some models)
Stainless Steel Refrigerator
Spill Shelf
Rotate
Drive
Mechanism
9
