Summary of Contents for GE Monogram ZFSB25D SS
- Page 1 Installation Instructions If you have questions, call 800.GE.CARES or visit our website at: www.monogram.com Free-Standing Side-by-Side Stainless Steel Refrigerator ZFSB25D SS ZFSB26D SS...
-
Page 2: Table Of Contents
Step 1A, Move Refrigerator Indoors (ZFSB26) ...6 Step 2, Install Water Line ...7 Safety Information CAUTION: Due to the weight and size of this refrigerator, and to reduce the risk of personal injury or damage to the product – TWO PEOPLE ARE REQUIRED FOR PROPER INSTALLATION. -
Page 3: Planning Information
The water line should be 1/4" O.D. copper tubing between the cold water line and water connection location at the rear of the refrigerator. Installation of an easily accessible shut ZFSB25 ZFSB26 off valve in the water line is recommended. -
Page 4: Tools Required
3-prong wall outlet. FLOORING For proper installation, this refrigerator must be placed on a level surface of hard material that is at the same height as the rest of the flooring. This surface should be strong enough to support a fully loaded refrigerator. -
Page 5: Step 1, Move Refrigerator Indoors (Zfsb25)
Installation Instructions STEP 1 MODEL ZFSB25 (GO TO STEP 1A FOR MODEL ZFSB26) MOVE REFRIGERATOR INDOORS IMPORTANT: Door and passageways into the installation location require a 31" min. opening. If the opening is less than 31", the top cap and doors must be removed. -
Page 6: Step 1A, Move Refrigerator Indoors (Zfsb26)
A. Remove 2 screws and springs on top of the refrigerator, one on each side. Push the top cap forward and lift up from the rear. B. Remove 2 screws holding the top filler strip, lift off. -
Page 7: Step 2 Install Water Line
To move the refrigerator indoors: • Place a piece of the carton or soft cloth against the side panel of the refrigerator to pad and protect the stainless steel finish. • Place the refrigerator on the handtruck with a side against the truck only. -
Page 8: Step 2A, Ro Water Line
GE RVKit must be used. For other reverse osmosis water systems, follow the manufacturer’s recommendations. If the water supply to the refrigerator is from a Reverse Osmosis Water System, use the refrigerator’s filter bypass plug. Using the refrigerator’s water filtration cartridge with the RO filter can result in hollow ice cubes and slower water flow from the water dispenser. -
Page 9: Step 6, Level Refrigerator
• The rollers adjust so that the door closes easily when opened about halfway. (Raise the front about 5/8" [16 mm] from the floor.) • Rollers adjust to allow the refrigerator to be firmly positioned on the floor and to prevent rocking when the doors are opened and closed. -
Page 10: Step 8 Start Icemaker
• To turn the icemaker off, set the switch to O (OFF). STEP 9 TEMPERATURE CONTROLS • The temperature controls are preset at 37° for the refrigerator and 0°F for the freezer. • Allow 24 hours to stabilize before making adjustments. STEP 10 INSTALL TOEKICK •... - Page 11 Notes...
- Page 12 Pub. No. 49-60476 Dwg. No. 197D4577P002 07-06 JR Printed in Mexico NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram ® local service in your area, call 1.800.444.1845. NOTE: Product improvement is a continuing endeavor at General Electric.
