Installation instructions for part 95-3306
Chevrolet Aveo 2007-2011/
Pontiac G3 2009-2010
KIT FEATURES
• ISO DDIN radio provision
KIT COMPONENTS
• A) Radio housing • B) Radio brackets
A
B
METRA - The World's best kits
®
95-3306
®
metraonline.com
Table of Contents
Dash Disassembly ..................................................2
Kit Assembly
–
ISO DDIN radio provision ...................................... 3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness:
• 70-2105
Antenna Adapter:
• 40-CR10
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32" socket wrench
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
Advertisement
Related Manuals for Metra Electronics 95-3306
Summary of Contents for Metra Electronics 95-3306
- Page 1 ® Installation instructions for part 95-3306 Chevrolet Aveo 2007-2011/ Table of Contents Pontiac G3 2009-2010 Dash Disassembly ..........2 95-3306 Kit Assembly – ISO DDIN radio provision ........3 KIT FEATURES • ISO DDIN radio provision WIRING & ANTENNA CONNECTIONS (sold separately) Wiring Harness: •...
- Page 2 ® 95-3306 Dash Disassembly 1. Unclip and remove the trim panel around radio. (Figure A) 2. Remove the (4) 9/32” screws securing the radio, and then unplug and remove. (Figure B) Continue to Kit Assembly SOUND SCAN SOUND SCAN (Figure A)
- Page 3 ® 95-3306 Kit Assembly ISO DDIN radio provision 1. Attach the radio brackets to the inside edge of the radio housing. 2. Slide the radio into the bracket/ radio housing assembly, and then secure using the screws supplied with the radio. (Figure A) 3.
- Page 4 ® Installation instructions for part 95-3306 IMPORTANT If you are having difficulties with the installation of this product, please call our Tech Support line at 1-800-253-TECH. Before doing so, look over the instructions a second time, and make sure the installation was performed exactly as the instructions are stated.
- Page 5 ® Instrucciones de instalación para la pieza 95-3306 Chevrolet Aveo 2007-2011/ Indice Pontiac G3 2009-2010 Desmontaje del tablero ..........2 95-3306 Ensamble del kit – Provisión de radio ISO DDIN ......... 3 CARACTERÍSTICAS DEL KIT • Provisión de radio ISO DDIN...
- Page 6 ® 95-3306 Desmontaje del tablero 1. Desenganche y quite el panel de moldura de alrededor del radio. (Figura A) 2. Retirar los (4) tornillos 9/32” que sujetan la radio y luego desconecte y quite. (Figura B) SOUND SCAN SOUND SCAN Continúe con el Ensamble del Kit...
- Page 7 ® 95-3306 Ensamble del kit Provisión de radio ISO DDIN 1. Coloque los soportes del radio en el borde interior de la carcasa del radio . 2. Deslice el radio en el soporte/ ensamble de carcasa del radio, y luego sujételo con los tornillos suministrados con el radio.
- Page 8 ® Instrucciones de instalación para la pieza 95-3306 IMPORTANTE Si tiene dificultades con la instalación de este producto, llame a nuestra línea de soporte técnico al 1-800-253-TECH. Antes de hacerlo, revise las instrucciones por segunda vez y asegúrese de que la instalación se haya realizado exactamente...
