Soundoff Signal PINNACLE Mini Lightbar Manual page 2

EPL7000 PINNACLE MINI
LIGHTBAR MAGNET MOUNT
EPL7M+(x)C
Replacement Parts & Accessories:
PMB3BMG: Replacement Magnetic Foot (each)
PMB3MGKT: Replacement Magnetic Mount (kit)
PMB3TDC: Replacement Clear Dome
TECHNICAL SPECIFICATIONS
Overall Dimensions: 14.25"L x 8.27"W x 2.93"H
Flash Patterns: 28 fl ash patterns
Input Voltage Range: 10 - 16 Vdc
Current Consumption: 2 Amps (Avg) - 4 Amps (Max)
# of LEDs: 24 Generation 3 LEDs
Operating Temperature: -40º to +65º C
Flash Patterns
Alternating Patterns (Flashes per Minute)
1. Warp
2. Quad
3. Quad2
4. Quint
5. Double2
6. Warp 1, 2, 3
7. Progressive
8. Q-Switch
9. Intercycle
10. Warp
11. Quad
12. Quad2
13. Quint
14. Double2
15. Warp 1, 2, 3
16. Progressive
17. Warp
18. Quad
19. Quad2
20. Quint
21. Double2
22. Warp 1, 2, 3
23. Progressive
24. Q-Switch
25. Intercycle
26. Rotator
27. Cycle 1
28. Cycle 2
FPM
Alternating
"
"
"
"
"
"
"
"
Whole Bar
"
"
"
"
"
"
Diagonal
"
"
"
"
"
"
"
"
"
Random
"
EPL7M+(x)C 6.09
