Soundoff Signal PINNACLE EPL7PD C Series Quick Start Manual

EPL7000 MINI LIGHTBAR PERMANENT MOUNT
EPL7PD(x)C Low Bracket (shown)
EPL7PD(x)A
EPL7HD(x)C High Bracket
EPL7HD(x)A
WARNING
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner's Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
1.800.338.7337 / www.soundoffsignal.com
1
Please see reverse for Technical Specifications
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
E N H A N C I N G S A F E T Y T H R O U G H I N N O VAT I O N
NOTICE:
INSTALLATION:
1) Determine a clean, flat location (typically roof) on
the vehicle to mount the PINNACLE Mini Lightbar.
The PINNACLE Mini Lightbar comes with two
(2) steel brackets which should be used to
permanently mount the light bar to a vehicle roof
or similar horizontal surface.
2) Position the bar with brackets attached and mark
hole centers. Center punch or drill pilot holes for a
1/4" sheet metal screw (customer supplied).
3) Place a locking washer over the screw and
securely fasten the brackets to the mounting
surface. The screws and holes should be caulked
with a silicone based material to prevent leakage.
DO NOT OVERTIGHTEN!
4) Make electrical connections.
Caution: Do not install this product or route any
wires in the air bag deployment zone. Refer to
your vehicle Owner's Manual for the location of
any air bag deployment zones.
WARNING
!
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into the
light beam at close range.
EPL7PD(x)C_EPL7000 0121
