1" Control Valve Series Model: WS1TC
1.25" Control Valve Series Model: WS1.25TC
T ÜRK
SU ARAŞTIRMA
MERKEZİ
Ayrıntılı Bilgi ve Sipariş için :
e-mail
: bilgi @ tusam.com.tr
web
: www. tusam .com .tr
Phone
: + 90 850 302 0 392
Please Note: This operation and instruction manual is for the training of
the OEM and for the OEM to use to train their customers. This document
is not to be used as the complete system manual.
Water Specialist
Operation and Instruction Manual for OEM Only.
T urkish
W ater
A ssociation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clack Water Specialist WS1TC
Summary of Contents for Clack Water Specialist WS1TC
- Page 1 Water Specialist 1” Control Valve Series Model: WS1TC 1.25” Control Valve Series Model: WS1.25TC T ÜRK T urkish SU ARAŞTIRMA W ater MERKEZİ A ssociation Ayrıntılı Bilgi ve Sipariş için : e-mail : bilgi @ tusam.com.tr : www. tusam .com .tr Phone : + 90 850 302 0 392 Operation and Instruction Manual for OEM Only.
- Page 2 MANUAL REGENERATION Arrow will point to Regen if a regen- eration is expected “Tonight.” NOTE: For softeners, if brine tank does not contain salt, fi ll with salt and wait at least 2 hours before regeneration. If you need to initiate a manual regeneration, either immediately, or tonight at the preprogrammed time (typically 2 a.m.), complete the following steps.
-
Page 3: Table Of Contents
Table of Contents Introduction ................................4 General Warnings (Must appear in OEM’s manual) ..................4 Specifi cations which must be included in OEM’s Manual ................5 Quick Reference Specifi cations ........................5 Control Valve Function and Cycles of Operation ....................6 Drive Assembly ..............................8 Drive Cap Assembly, Downfl ow Piston and Regenerant Piston ..............8 Spacer Stack Assembly .............................8 Injector Cap, Screen, Injector Plug and Injector ....................9 Refi... -
Page 4: Introduction
Page 4 WS1TC & WS1.25 TC Manual Introduction This manual is about a control valve to be used on water softeners or water fi lters. The manual is designed to aid water treatment equipment manufacturers in the selection of the various control valve options. Information in this manual is different than what is needed for installation and servicing of a particular water treatment system. -
Page 5: Specifi Cations Which Must Be Included In Oem's Manual
WS1TC & WS1.25 TC Manual Page 5 Table 1 Specifi cations which must be included in OEM’s Manual Minimum/Maximum Operating Pressures 20 psi (138 kPa) -125 psi (862 kPa) Minimum/Maximum Operating Temperatures 40°F (4°C) - 110°F (43°C) AC Adapter: U.S. International Supply Voltage 120 V AC... -
Page 6: Control Valve Function And Cycles Of Operation
Page 6 WS1TC & WS1.25 TC Manual Control Valve Function and Cycles of Operation This glass fi lled Noryl (or equivalent) fully automatic control valve is designed as the primary control center to direct and regulate all cycles of a downfl ow regeneration water softener or fi lter. The time clock control valve can be set to perform downfl... - Page 7 WS1TC & WS1.25 TC Manual Page 7 The user can initiate manual regeneration. The user has the option to request the manual regeneration at the delayed regeneration time or to have the regeneration occur immediately. Simultaneously press the UP + DOWN buttons to start a regeneration at the next delayed regeneration time.
-
Page 8: Drive Assembly
Page 8 WS1TC & WS1.25 TC Manual Drive Assembly The drive assembly consists of the following parts: • Drive Bracket • Printed Circuit (PC) Board • Motor • Drive Gears • Drive Gear Cover The drive bracket holds the PC board, the motor, the drive gears and the drive gear cover in place. The PC board receives and retains information, displays the information, determines when to regenerate and initiates regeneration. -
Page 9: Injector Cap, Screen, Injector Plug And Injector
WS1TC & WS1.25 TC Manual Page 9 Injector Cap, Screen, Injector Plug and Injector The screen, injector and/or injector plug(s) are installed under the injector cap in an easy to access location on top of the valve. The injector cap contains four slots so no water accumulates in the cap. The injector cap is designed to be hand tightened. Under the injector cap there is an easy to clean removable screen to prevent fouling of the injector. -
Page 10: Drain Line Flow Control And Fitting Assembly
Page 10 WS1TC & WS1.25 TC Manual The refi ll fl ow control assembly is installed in an easy to access refi ll elbow located on top of the control valve. The refi ll fl ow control assembly is attached to the control valve with a locking clip. The locking clip allows the elbow to rotate 270 degrees so the outlet can be orientated towards the regenerant tank. -
Page 11: Mixing Valve
WS1TC & WS1.25 TC Manual Page 11 Mixing Valve The mixing valve is installed on the outlet side of the control valve. The mixing valve is used to blend raw water with treated water. To adjust the blended water, close the mixing valve. Open a water faucet to the desired fl ow rate. Open the mixing valve until the desired hardness is reached. -
Page 12: Bypass Valve
Page 12 WS1TC & WS1.25 TC Manual Bypass Valve The bypass valve is typically used to isolate the control valve from the plumbing system’s water pressure in order to perform control valve repairs or maintenance. The WS1 bypass valve is particularly unique in the water treatment industry due to its versatility and state of the art design features. - Page 13 WS1TC & WS1.25 TC Manual Page 13 Figure 1 Figure 2 Figure 3 Figure 4...
-
Page 14: Oem General Instructions
Page 14 WS1TC & WS1.25 TC Manual OEM General Instructions The control valve offers multiple procedures that allow the valve to be modifi ed to suit the needs of the installation. These procedures are: • OEM System Setup • Installer Displays & Settings (either 1-99 Days Between Regeneration option or 7-Day option) •... - Page 15 WS1TC & WS1.25 TC Manual Page 15 STEP 4SS STEP 4SS — Use UP or DOWN buttons to switch between: • 1-99 Days Between Regen; or • 7-Day. Press SET HOUR button to go to Step 5SS. STEP 5SS STEP 5SS — Use UP or DOWN buttons to switch between 60 Hz or 50 Hz option.
-
Page 16: Installer Displays/Settings
Page 16 WS1TC & WS1.25 TC Manual Installer Displays & Settings (1-99 Days Between Regeneration option) STEP 1ID STEP 1ID – From normal mode, press SET HOUR + UP buttons simultaneously for 3 seconds and release. STEP 2ID STEP 2ID – Regeneration Time: Set the clock to the hour the regeneration should occur by using the UP or DOWN buttons. -
Page 17: User Displays/Settings
WS1TC & WS1.25 TC Manual Page 17 STEP 6I7 STEP 6I7 – Tuesday Regeneration: To regenerate on Tuesday use the UP or DOWN button until the arrow points to Regen. If the arrow does not point to Regen a regeneration will not occur on Tuesday. - Page 18 Page 18 WS1TC & WS1.25 TC Manual Manual Regeneration An arrow will point Sometimes there is a need to regenerate the system sooner than when the system calls for it, usually referred to as to the word Regen if a regeneration is a manual regeneration.
-
Page 19: Installation
WS1TC & WS1.25 TC Manual Page 19 and tighten the nut on to the ¾” drain line fi tting. The nut is only designed for use with fl exible polytube. Use other nuts if attaching different materials. To access the drain line fl ow control remove the locking clip by pulling it straight out. Pull fi tting out and replace the locking clip so that it is not misplaced. - Page 20 Page 20 WS1TC & WS1.25 TC Manual Mixing Valve The mixing valve is an option on the control valve. If the control valve is ordered with a mixing valve it will be installed in the control valve assembly process. To adjust the blended water, close the mixing valve. Open a water faucet to the desired fl ow rate. Open the mixing valve until the desired hardness is reached.
-
Page 21: Drawings And Part Numbers
WS1TC & WS1.25 TC Manual Page 21 Drawings and Part Numbers... -
Page 22: Front Cover And Drive Assembly
Page 22 WS1TC & WS1.25 TC Manual Front Cover and Drive Assembly Drawing No. Order No. Description Quantity V3175TC-01 WS1TC Front Cover ASY V3107-01 WS1 Motor V3106-01 WS1 Drive Bracket & Spring Clip V3108TC WS1TC PC Board V3110 WS1 Drive Gear 12 x 36 V3109 WS1 Drive Gear Cover V3002TC... -
Page 23: Ws1Tc Drive Cap Assembly, Downfl Ow Piston, Regenerant Piston And Spacer Stack Assembly
WS1TC & WS1.25 TC Manual Page 23 WS1TC Drive Cap Assembly, Downfl ow Piston, Regenerant Piston and Spacer Stack Assembly Drawing No. Order No. Description Quantity V3005 WS1 Spacer Stack Assembly V3004 Drive Cap ASY V3178 WS1 Drive Back Plate V3011 WS1 Piston Downfl... -
Page 24: Ws1.25Tc Drive Cap Assembly, Downfl Ow Piston, Regenerant Piston And Spacer Stack Assembly
Page 24 WS1TC & WS1.25 TC Manual WS1.25TC Drive Cap Assembly, Downfl ow Piston, Regenerant Piston and Spacer Stack Assembly Drawing No. Order No. Description Quantity V3430 WS1.5 Spacer Stack Assembly V3004 Drive Cap ASY V3178 WS1 Drive Back Plate V3407 WS1.5 Piston Downfl... -
Page 25: Injector Cap, Injector Screen, Injector, Plug And O-Ring
WS1TC & WS1.25 TC Manual Page 25 Injector Cap, Injector Screen, Injector, Plug and O-Ring Drawing No. Order No. Description Quantity V3176 Injector Cap V3152 O-ring 135 V3177 Injector Screen V3010-1Z WS1 Injector ASY Z Plug V3010-1A WS1 INJECTOR ASY A BLACK V3010-1B WS1 INJECTOR ASY B BROWN V3010-1C... -
Page 26: Refi Ll Flow Control Assembly And Refi Ll Port Plug
Page 26 WS1TC & WS1.25 TC Manual Refi ll Flow Control Assembly and Refi ll Port Plug Drawing No. Order No. Description Quantity V3195-01 WS1 Refi ll Port Plug ASY This part is required for backwash only systems H4615 Elbow Locking Clip JCP-P-6 Polytube insert 3/8”... -
Page 27: Drain Line - 3/4
WS1TC & WS1.25 TC Manual Page 27 Drain Line – 3/4” Drawing No. Order No. Description Quantity H4615 Elbow Locking Clip PKP10TS8-BULK Polytube insert 5/8 Option V3192 WS1 Nut ¾ Drain Elbow Option V3158-01 WS1 Drain Elbow ¾ Male V3163 O-ring 019 V3159-01 WS1 DLFC Retainer ASY... -
Page 28: Drain Line - 1
Page 28 WS1TC & WS1.25 TC Manual Drain Line – 1” Drawing No. Order No. Description Quantity H4615 Elbow Locking Clip V3008-02 WS1 Drain FTG 1 Straight V3166 WS1 Drain FTG Body 1 V3167 WS1 Drain FTG Adapter 1 V3163 0-ring 019 V3150 WS1 Split Ring... -
Page 29: Meter Plug And Mixing Valve
WS1TC & WS1.25 TC Manual Page 29 Meter Plug and Mixing Valve Drawing No. Order No. Description Quantity V3151 WS1 Nut 1” QC V3005 O-ring 215 V3003-01 WS1 Meter Plug ASY V3013 Mixing Valve Optional... -
Page 30: Installation Fitting Assemblies
Page 30 WS1TC & WS1.25 TC Manual Installation Fitting Assemblies Order No: V3007 Order No: V3007-01 Description: WS1 Fitting 1” PVC Male NPT Elbow Assembly Description: WS1 Fitting ¾” & 1” PVC Solvent 90° ASY Drawing No. Order No. Description Quantity Drawing No. - Page 31 WS1TC & WS1.25 TC Manual Page 31 Installation Fitting Assemblies Order No: V3007-04 Order No: V3007-05 Description: WS1 Fitting 1” Plastic Male NPT Assembly Description: WS1 Fitting 1-¼” Plastic Male Assembly Drawing No. Order No. Description Quantity Drawing No. Order No. Description Quantity V3151...
-
Page 32: Bypass Valve
Page 32 WS1TC & WS1.25 TC Manual Bypass Valve Drawing No. Order No. Description Quantity V3151 WS1 Nut 1” Quick Connect V3150 WS1 Split Ring V3105 O-Ring 215 V3145 WS1 Bypass 1” Rotor V3146 WS1 Bypass Cap V3147 WS1 Bypass Handle V3148 WS1 Bypass Rotor Seal Retainer V3152... -
Page 33: Flow Diagrams - Service And Backwash
WS1TC & WS1.25 TC Manual Page 33 Flow Diagrams – Service and Backwash... -
Page 34: Flow Diagrams - Downfl Ow Brine And Rinse
Page 34 WS1TC & WS1.25 TC Manual Flow Diagrams – Downfl ow Brine and Rinse... -
Page 35: Flow Diagrams - Fill
WS1TC & WS1.25 TC Manual Page 35 Flow Diagrams – Fill... -
Page 36: Ws1 Wrench
Page 36 WS1TC & WS1.25 TC Manual WS1 Wrench (Order No. V3193-01) Although no tools are necessary to assemble or disassemble the valve, the WS1 wrench (shown in various positions on the valve) may be purchased to aid in assembly or disassembly. /RRVHQV 'UDLQ 1XW ,Q 3RO\WXEH $SSOLFDWLRQV /RRVHQV ,QMHFWRU $QG... -
Page 37: Service Instructions
WS1TC & WS1.25 TC Manual Page 37 Service Instructions Drive Assembly Remove the valve cover to access the drive assembly. Disconnect the power source plug (black wire) from the PC board prior to disconnecting the motor plug from the PC board. The power source plug connects to the four-pin jack. - Page 38 Page 38 WS1TC & WS1.25 TC Manual Replace the motor if necessary. Do not lubricate the motor or the gears. To reinstall the motor, move the spring clip loop to the right and hold. Gently turn the motor while inserting so that the gear on the motor meshes with the gears under the drive gear cover. Release the spring clip loop and continue to rotate the motor until the wires are horizontal and the motor housing engages the small plastic bulge inside the drive bracket motor retainer.
- Page 39 WS1TC & WS1.25 TC Manual Page 39 The regenerant piston (the small diameter one behind the main piston) is removed from the main piston by pressing sideways and unsnapping it from its latch. Chemically clean in dilute sodium bisulfi te or vinegar, or replace the regenerant piston if needed. To remove the main piston fully extend the piston rod and then unsnap the main piston from its latch by pressing on the side with the number.
- Page 40 Page 40 WS1TC & WS1.25 TC Manual Two holes are labeled DN and UP. Check for compliance. See Table. Compliance Table Regenerant Application Injector and/or Plug(s) Main Piston Stack Body Piston WS1TC Downfl ow Injector in “DN” hole, Plug V3001 or Softener or Regenerating V3011 V3174...
- Page 41 WS1TC & WS1.25 TC Manual Page 41 Mixing Valve The mixing valve is installed on the outlet side of the control valve. The mixing valve is used to blend raw water with treated water. To adjust the blended water, close the mixing valve. Open a water faucet to the desired fl ow rate. Open the mixing valve until the desired hardness is reached.
-
Page 42: Troubleshooting
Page 42 WS1TC & WS1.25 TC Manual Table 6 Troubleshooting Procedures Problem Possible Cause Solution a. AC Adapter unplugged a. Connect power b. No electric power at outlet b. Repair outlet or use working outlet 1. Timer does not display time of c. -
Page 43: Ws1Tc & Ws1.25Tc Identifi Cation
WS1TC & WS1.25 TC Manual Page 43 Figure 6 WS1TC & WS1.25TC Identifi cation WS1TC with 1.050" Distributer Tube Opening Identifi cation Spacer Color: Grey 1.25" Black Plug 1.25" Note: The WS1TC downfl ow piston is a solid amber color. WS1.25TC with 1.32"... -
Page 44: Injector Graphs Us Units: Injector Draw, Slow Rinse And Total Flow Rates
Page 44 WS1TC & WS1.25 TC Manual... - Page 45 WS1TC & WS1.25 TC Manual Page 45...
-
Page 46: Injector Graphs Metric Units: Injector Draw, Slow Rinse And Total Flow Rates
Page 46 WS1TC & WS1.25 TC Manual... - Page 47 WS1TC & WS1.25 TC Manual Page 47...
-
Page 48: Limited Warranty
Valves from Clack’s plant in Windsor, Wisconsin when installed and operated within recommended parameters. No warranty is made with respect to defects not reported to Clack within the warranty period and/or defects or damages due to neglect, misuse, alterations, accident, misapplication, physical damage, or damage caused by fi...
