The bypass valve is typically used to isolate the control valve from the plumbing system’s water pressure in order to perform control valve repairs or maintenance. The WS 1 bypass valve is particularly unique in the water treatment industry due to its versatility and state of the art design features. The 1″ full flow bypass valve incorporates four positions including a diagnostic position that allows service personal to work on a pressurized system while still providing untreated bypass water to the facility or residence.
Page 2
2. Bypass Position: The inlet and outlet handles point to the center of the bypass, the control valve in isolated from the water pressure contained in the plumbing system. Untreated water is supplied to the plumbing system. 3. Diagnostic Position: The inlet handle points in the direction of flow and the outlet handle points to the center of bypass valve, system water pressure is allowed to the control valve and the plumbiiig system while not allowing water to exit from the control valve to the plumbing.
Page 3
Front Cover and Drive Assembly for WS1 Clack water softener valve Drawing No. Order No. Description Quantity V3175-01 WS 1 Front Cover ASY V3107-01 WS 1 Motor V3106-01 WS 1 Drive Bracket & Spring Clip V3108 WS 1 PC Board V3110 WS 1 Drive Geart 12×36...
Page 4
V3005 WSI Spacer Stack Assembly V3004 Drive Cap ASY V3135 0-ring 228 V3011* WS 1 Piston Downflow ASY V301 1-01 WS1 Piston Upflow ASY 1 V3174 WS 1 Regenerant Piston V3180 0-ring 337 V3O11 is labeled with DN and V3011-01 is labeled with UP.
Page 5
Description Quantity V3176 Injector Cap V3152 0-ring 135 V3177 Injector Screen V3010-IZ WS 1 Injector ASY Z Plug V3010-1A WS1 INJECTOR ASYABLACK V3010-IB WS1 INJECFORASY B BROWN V3010-IC WS1 INJECTOR ASY C VIOLET V30I0-ID WS1 INJECTOR ASYDRED V3010-1E WS1 INJECTOR ASYE WHITE...
Page 6
This part is required for backwash only systems H4615 Elbow Locking Clip JCP-P-6 Polytube insert 3/8 JCPG-6PBLK Nut 3/8 014613 Elbow Cap 318 V3163 0-ring019 V3165_01* WS 1 RFC Retainer ASY V3182 WS1RFC Not Shown H4650 Elbow 1/2″ with nut and insert Option...
Page 8
WS1 Split Ring 7° V3151 WS1 Nut 1” QC V3105 O-ring 215 V3190-090 WS 1 DLFC 9.0 gpm for 1 V5190-100 WS 1 DLFC 10.0 gpm for 1 V3190-110 WS 1 DLFC 11.0 gpm for 1 DLFC V3190-130 WS 1 DLFC 13.0 gpm for 1...
Page 9
V3190-170 WS 1 DLFC 17.0 gym for 1 1″ fitting V3190-200 WS 1 DLFC 20.0 gym for 1 is used V3190-250 WS1 DLFC 25.0 gym for 1 Can be ordered us a set order number V3008-02, description: WS1 Drain FTG 1 Straight.
Page 10
Drawing no order no description quantity V3151 WS1 Nut 1 “ Quick Connect V3l50 WS 1 Split Ring V3105 O-Ring 215 V3149 WS1 Fitting 1 PVC Male NPT Elbow Order No: V3007 Description: WS1 Fitting 1” PVC Male NPT Elbow Assembly...
Page 11
WS1 Fitting 1” Brass Sweet Order No: V3007-03 Description: WSJ Fitting 3/4’” Brass Sweat Assembly Drawing no order no description quantity V3151 WS1 Nut 1” Quick Connect V3150 WS1 Split Ring V3105 O-Ring 215 V3188-01 WS 1 Fitting ¾ Brass Sweat Bypass Valve...
Page 13
Drive Assembly Remove the valve cover to seems the drive assembly Disconnect the power source plug (black wire) from the PC board prior to disconnecting the motor or water meter plugs from the PC board. The motor plug connects to the two-pin jack on the left-hand side of the PC board.
Page 14
Replace broken or damaged drive gears. Do not lubricate any of the gears. Avoid getting any foreign matter on the reflective coating became dirt or oils may interfere with pulse counting. The drive gear cover only fits on one way, with the large clip orientated towards the bottom. If all three clips are outside of the gear shroud on the drive bracket the drive gear cover slips easily into place.
Page 15
The drive cap assembly contains the drive cap, the main drive gear, drive cap spline, piston rod and various other parts that should not be dissembled in the field. The only replaceable part on the drive cap assembly is the 0-ring. Attached to the drive cap assembly is the main piston (down flow or up flow) and if a regenerant is used, a regenerant piston.
Page 16
After completing any valve maintenance, press and hold NEXT and REGEN buttons for 3 seconds or unplug power source jack (black wire) and plug back in. This resets the electronics and establishes the service piston position The display should flash all wording, then flash the soft ware version and then reset the valve to the service position.
Page 17
The water meter assembly is connected to the PC board by a wire. If the entire water meter assembly is to be replaced, remove the control valve cover and remove the power source and water meter plugs from the PC board. Unlatch the drive assembly and lean it forward. Unthread the water meter wire from the side of the drive assembly and through the drive back plate.
Since the handles can be pulled off, they could be accidentally reinstalled I 80°° from their correct orientation. To install the red arrow handles correctly, keep the handles pointed in the same direction as the arrows engraved on the control valve body while tightening II bypass valve caps. After completing any valve maintenance, press and hold NEXT and REGEN buttons for 3 seconds or unplug power source jack (black wire) and plug back in.
Page 19
Time of day not set correctly b. Reset to correct time of day Time of regeneration incorrect c. Reset regeneration time Control valve set at “ on 0″ d. Check control valve set-up procedure (immediate regeneration) regeneration time option Control valve set at NORMAL + c. Check control valve set-up procedure on 0 regeneration time option ERROR followed by code number...
Page 20
missing or broken gear Drive bracket incorrectly aligned to back plate g. Resent drive bracket properly PC board is damaged or defective h. Replace PC board i.PC board incorrectly aligned to i.Ensure PC board is correctly snapped drive bracket onto drive bracket Problem Possible Cause Solution...
Page 21
or foreign matter Defective meter d. Replace meter Defective PC board . e. Replace PC board Set-up error f.Check control valve set-up procedure Time of day flashes on and off Power has been out more than two a. Reset the time of day hours, the transformer was unplugged and then plugged back into the wall outlet, the...
