- Page 1 Model: AV-1161 HD-SDI Box IP Camera User Manual V1.2 (English) Please read this user manual thoroughly before using. www.avipas.com...
- Page 2 Preface Thank you for using this HD Video Conferencing Camera. This manual introduces the functions, installation process and operation of the HD camera. Prior to installation and usage, please read the manual thoroughly. Precautions This product should only be used under the specified conditions in order to avoid any damage to the camera: ◼...
-
Page 3: Table Of Contents
Catalogue ABOUT THE PRODUCT -------------------------------------------------------------- 1 ---------------------------------------------------------------------------------------------- 1 FEATURES & --------------------------------------------------------------------- 1 LIST OF PARTS ACCESSORIES & ------------------------------------------------------------------------- 2 MAIN PARTS INTERFACES INSTALLATION AND CONNECTION -------------------------------------------- 3 ---------------------------------------------------------------------------------------- 3 INSTALLATION ------------------------------------------------------------------------------------------ 4 CONNECTION OPERATION ----------------------------------------------------------------------------- 5 ------------------------------------------------------------------------------------ 5 ZOOM AND FOCUS --------------------------------------------------------------------------------------------------- 5 MENU ------------------------------------------------------------------------------- 5... -
Page 4: About The Product
ABOUT THE PRODUCT Power Adapter (1) 1.1 Features ◼ 1/3” CMOS sensor, 2.14MP; ◼ 5x optical zoom; ◼ Support multi control methods: LAN / RS-232 / RS-485 / rear panel RS-232/ RS-485 Connector（2） button; ◼ Support SDI and network interface, simultaneous full HD video output;... -
Page 5: Main Parts & Interfaces
1.3 Main Parts & Interfaces Side View 1.3.1 Camera Front View 1 Camera Lens 12 Mounting Hole 1/4” screw, used to fix the camera Rear View 2 Button Operation 3 RS-485 Control Interface 4 RS -232 Control Interface 7 HD-SDI Interface 8 Network Interface 9 Audio Interface 10 Power Indicator... -
Page 6: Installation And Connection
INSTALLATION AND CONNECTION 2.1 INSTALLATION The camera can be installed on a wall mount. NOTE Before installing, make sure Use screws to secure the camera there is enough space to install on the bracket. Make sure the the camera with all parts/cable. camera is tightly fixed onto the Make sure the installed place is stable and safe enough to hold... -
Page 7: Connection
2.2 CONNECTION Before powering on, make sure all connections are correct and secure. -
Page 8: Operation
PRESETS LIST OPERATION Preset Please refer to “INSTALALTION AND Function Number CONNECITON” on page 3. Enter into menu video format: 1920X1080P25 video format: 1280*720p50 Installation mode: STAND Installation mode: CEILING 3.1 ZOOM AND FOCUS Video format: 1920X1080P30 Video format: 1280*720p60 Press to zoom in / zoom out the Image distortion... -
Page 9: Menu Configuration
MENU CONFIGURATION <VIDEO> IMAGE MODE MODE1, MODE2, MODE3 (Please refer page SHARPNESS 0 ~ 15 CONTRAST 1 ~ 15 GAMMA MODE 0, 1, 2, 3, 4, DNR LEVEL ON, OFF LDC LEVEL 1~10, OFF BACK <EXPOSUR EXP-COMP -7, -6, -5, -4, -3, -2, -1, 0, +1, +2, +3, +4, +5, +6, +7 E>... -
Page 10: Menu Explanation
< SYSTEM > ADDRESS 1, 2, 3, 4, 5, 6, 7 Please refer PROTOCOL VISCA, PELCO-P, PELCO-D page 10 BAUD RATE 2400, 4800, 9600, 38400 VIDEO FORMAT 1080P30, 1080P25, 720P60, 720P50 MOUNTING MODE STAND, CEILING RS485 PORT HALF-DUPLEX-1, HALF-DUPLEX-2 LANGUAGE ENGLISH, CHINESE FIRMWARE VER V2.0.03... -
Page 11: Video
❶ Submenu ❶ <EXPOSURE> EXP-COMP ❸ Set Parameters ❷ Press to change value ❷. Current setting ANTI-FLICKER ❸ BACK contrast of the whole image. The higher 5.2 VIDEO ]SELECT the level is, the steeper of the Gamma VIDEO menu is used to change video curve will be. -
Page 12: System
EXP-COMP: -7, -6, -5, -4, -3, -2, -1, 0, “ONE PUSH” mode: Press +1, +2, +3, +4, +5, +6, +7。 button select “ONE PUSH TRIGGER”. Used for focusing the +7 is the max compensation value for camera at a pure white object (say a bright exposure while -7 is the max white paper), then press button. -
Page 13: Restore Defaults
LANGUAGE: ENGLISH, CHINESE. 5.6 RESTORE DEFAULTS < RESTORE DEFAULTS> PRESS OK TO CONFIRM BACK ]BACK RESTORE DEFAULTS: This option is used to reset all parameters to default values. NETWORK Please refer to “ReadMe.docx”. Go to AV-1161 page on www.avipas.com. -
Page 14: Annex 1 Technical Specifications
ANNEX 1 TECHNICAL SPECIFICATIONS Image Sensor 1/3" CMOS,2.14 megapixel Max Resolution 1920*1080 Focal Lens f=2.8mm-14mm Optical Zoom Field of View 32°~84° Focus System Manual Min. Illumination 0.5 lux White Balance Auto Exposure Control Auto Control Buttons SDI output Video output 1080P30/ 1080P25/ 720P60/ 720P50 Network Resolution... -
Page 15: Annex 2 Size And Dimension
ANNEX 2 SIZE AND DIMENSIONS Front Rear Side Bottom... - Page 16 ANNEX 3 RECOMMENDATION DISTANCE FOR EXTENSION POWER CABLE Nominal sectional area +20°C DC Resistance Recommended distance ≤ (Ω/km) (mm2) 36.0 0.5667 26.9 0.75 24.5 18.1 1.318 13.5 12.1 2.075 8.45 7.41 3.332 5.31 4.61 5.26 3.36 3.08...
-
Page 17: Trouble Shooting
TROUBLE SHOOTING Problem Possible Cause Solution Power supply failure Check power supply No lens action or video Power adapter damaged Replace power adapter after power on Loose power cable Check & reconnect connection Set the address, protocol and control Incorrect connection or baud rate according to the camera after powering open circuit of RS-485/... - Page 18 Warranty Period. AVIPAS Inc. will repair or replace the qualified products at no charge. AVIPAS Inc. provides a two (2)-year warranty (from the date of purchase) for this HD Conference Camera. This Limited Warranty does not cover problems including but not limited to: improper handling, malfunction or damage not resulting from defects in material.
