USER MANUAL FOR COMFLEX-4500 5W
Installed on the wall
Step 1: Measure and mark two holes on the wall nearby RU, the max. demision from RU is 0.5m.
4.37
Figure 25: Mounting Rack Installation (Unit: inch)
Step 2: Screw two hexagonal masonry bolts M8 x 80 to fasten the PSU on the wall.
Figure 26: Remote PSU wall mounting
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 30
