2.2

Explanation of icons

Symbol Description
Indicates technical aspects which the
user must observe.
Switch off machine
Switch on machine
Incorrect / Invalid
Correct / Valid
Input
Navigation
Output
Time representation (e.g.: wait 4 s /
actuate)
Interruption in the menu display (other
setting options possible)
Tool not required/do not use
Tool required/use
099-008593-EW501
26.07.2019
For your safety
Symbol Description
Activate and release / Tap / Tip
Release
Press and hold
Switch
Turn
Numerical value – adjustable
Signal light lights up in green
Signal light flashes green
Signal light lights up in red
Signal light flashes red
Explanation of icons
5
