DEMO MANUAL DC1836A
parts list
iTEm
QTY
rEFErEnCE
required Circuit Components
1
0
C1
2
1
C2
3
0
C3, C7
4
1
C4
5
1
C5
6
1
C6
7
1
C8
8
1
C9
9
13
E1-E13
10
5
JP1-JP5
11
5
XJP1-XJP5
12
2
D1, D2
13
1
D3
14
1
D4
15
1
R1
16
2
R2, R4
17
1
R3
18
0
R5, R7
19
1
R8
20
1
R9
21
1
R10
22
4
R11, R12, R13, R14
23
2
R6, R19
24
1
SW1
25
1
U3
26
2
U6, U7
27
2
DC1836A-A required Circuit Components
1
1
U1
2
2
R15, R16
3
0
R17, R18
4
1
DC1836A-B required Circuit Components
1
1
U1
2
2
R17, R18
3
0
R15, R16
4
1
4
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
PArT DESCriPTiOn
CAP ., OPT, 1206
CAP ., X7R, 0.1µF , 50V, 10%, 0805
CAP ., OPT, 0603
CAP ., X5R, 0.47µF , 10V, 10%, 0603
CAP ., X5R, 1µF , 10V, 10%, 0603
CAP ., X7R 10nF 10V, 10%, 0603
CAP ., X5R, 2.2µF , 10V, 10%, 0603
CAP ., X5R, 0.1µF , 10V, 10%, 0603
TP , TURRET, 0.064", PAD120-064
HD1×3-079
SHUNT
LED, GREEN
LED, RED
LED, AMBER
RES., CHIP , 1k, 1/10W, 1%, 0603
RES., CHIP , 200k, 1/16W, 1%, 0402
RES., CHIP , 5.1k, 1/16W, 1%, 0402
RES., OPT., 0402
RES., CHIP , 100k, 1/16W, 1%, 0402
RES., CHIP , 845k, 1/16W, 1%, 0402
RES., CHIP , 115k, 1/16W, 1%, 0402
RES., CHIP , 475, 1/16W, 1%, 0402
RES., CHIP , 10k, 1/16W, 1%, 0402
SWITCH, PUSHBUTTON
I.C., LT3060ETS8, TS8
I.C., LT6700CS6-1, SOT23-6
STENCIL TOP AND BOTTOM
I.C., LTC2955IDDB-1, DFN10DDB
Res., Chip, 100k, 1/16W, 1%, 0402
Res., OPT., 0402
FAB, PRINTED CIRCUIT BOARD
I.C., LTC2955IDDB-2, DFN10DDB
Res., Chip, 100k, 1/16W, 1%, 0402
Res., OPT., 0402
FAB, PRINTED CIRCUIT BOARD
mAnuFACTurEr/PArT numBEr
AVX, 08055C104KAT2A
TAIYO YUDEN, LMK107BJ474KA
AVX, 0603ZD105KAT2A
AVX, 0603ZC103KAT2A
MURATA, GRM188R61A225K
AVX, 0603ZD104KAT2A
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, TMM103-02-L-S
SAMTEC, 2SN-BK-G
PANASONIC, LN1351-C-TR
PANASONIC, LN1251-C-TR
PANASONIC, LN1451-C-TR
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW0402200KFKED
VISHAY, CRCW04025K10FKED
VISHAY, CRCW0402100KFKED
VISHAY, CRCW0402845KFKED
VISHAY, CRCW0402115KFKED
VISHAY, CRCW0402475RFKED
VISHAY, CRCW040210KFKED
PANASONIC, EVQPJS05K
LINEAR TECHNOLOGY, LT3060ETS8
LINEAR TECHNOLOGY, LT6700CS6-1
STENCIL, DC1836A
LINEAR TECHNOLOGY, LTC2955IDDB-1
VISHAY, CRCW0402100KFKED
DEMO CIRCUIT 1836A
LINEAR TECHNOLOGY, LTC2955IDDB-2
VISHAY, CRCW0402100KFKED
DEMO CIRCUIT 1836A
