- Page 1 2 BIKE LOCK AND TILTING PLATFORM HITCH RACK - SR2901LR 90 lb. total 45 lb. per tray PARTS INCLUDED Bicycle Installation Weight Limitation Receiver Installation Tighten Well...
-
Page 2: Warnings / Limitations
WARNINGS / LIMITATIONS • Fits 20-29" wheels up to 3" wide. • 2 Bike maximum carrying capacity = 90 lbs./40Kg • Can work with bikes with fenders. • Not intended for off-road use. • Not intended for tandems or recumbents. •... - Page 3 17 mm Tighten Well FOOT INSTALLATION FOR 1 1/4" RECEIVERS 3/4" • Lock should click onto the end of the bolt. Receiver Installation Tighten Well...
- Page 4 FOOT INSTALLATION FOR 2" RECEIVERS 3/4” ¾ po 1,9 cm • Lock should click onto the end of the bolt. Receiver Installation Tighten Well THE RACK IS NOW READY TO LOAD BIKES.
- Page 5 • Raise the hooks by depressing the grey buttons and sliding the hooks upward on the mast. Bicycle Installation • Place the bike on the bike tray with the wheels in the wheel trays and push down hook firmly until top tube fits snug against top bend of hook underside.
- Page 6 • To lock the bikes to the carrier. Learn more about bike racks on our website.
