SportRack SR1008 Installation Instructions

SportRack SR1008 Installation Instructions

Complete roof rack system

Advertisement

1
3
4
J
X
501-5974
COMPLETE
ROOF RACK
• Tighten screw X to 6Nm /
53 in-lbs.
SYSTEM - SR1008
2
J
X
• Using the included fit chart, adjust foot positions to the numbers for your vehicle.
Use "Front" dimensions for front bar and "Rear" for rear bar.
5
• Unscrew X with the tool
included.
• Unscrew Y.
Y
