SportRack SR3161 Quick Start Manual

2/3 bike anti-sway trunk mount rack

80" strap

• Number of bicycles carried should not exceed

designated carrying capacity for your specific

SportRack model.

• SR3161 (2 bike) max carrying capacity = 70lbs.

• SR3152 (3 bike) max carrying capacity = 105lbs.

• Check tightness of all bolts and knobs periodically.

• Check straps for wear and replace if worn.

• Not intended for off-road use.

• Not intended for tandems or recumbents.

• Do not install on a trailer or other towed vehicle.

• Failure to use safety strap may result in loss

of bicycles.

501-5998

2 BIKE ANTI-SWAY TRUNK MOUNT RACK - SR3161

3 BIKE ANTI-SWAY TRUNK MOUNT RACK - SR3152

Upper support leg

Lower support leg

Adjustable hub

Knob

Anti-Sway soft rubber cradles

Padding

WARNINGS / LIMITATIONS

Bike support arms

Table of Contents

Do you have a question about the SR3161 and is the answer not in the manual?

Page 1 • Number of bicycles carried should not exceed designated carrying capacity for your specific SportRack model. • SR3161 (2 bike) max carrying capacity = 70lbs. • SR3152 (3 bike) max carrying capacity = 105lbs. • Check tightness of all bolts and knobs periodically.
Page 2 • Clean trunk/hatch and rear of car. • Choose the illustration that most closely approximates the installation of the SR3161/SR3152 on your vehicle. • Loosen the two adjustable hub assemblies by untightening the two knobs. • Move the upper support leg until the SR3161/SR3152 is set approximately to the same angle as in Step 2 that closely resembles your vehicle.
Page 3 ATTACH UPPER HOOKS • Once you have the SR3161/SR3152 assembled to its proper setting, place it on the vehicle. Now attach the two upper hooks into the slot at the leading edge of the trunk or hatch lid. Adjust the straps lengths so the SR3161/SR3152 stays in place on the car in the desired position.
Page 4 MOUNTING BICYCLES ONTO YOUR TRUNK-MOUNTED BICYCLE CARRIER Rear of Bicycle • Place the bicycle(s) onto the SR3161/SR3152 • Making figure 8 shapes around the last bicycle • For maximum security, we recommend that a support arms in the bicycle cradles. Make sure frame and the SR3161/SR3152 arms with the simple knot be tied at the end of the buckle.

Sr3152
