- Page 1 4 BIKE LOCK AND TILTING PLATFORM HITCH RACK - SR2902LR Hitch must have a minimum Class II rating. 180 lb. total 45 lb. per tray PARTS INCLUDED Bicycle Installation Weight Limitation Receiver Installation Tighten Well 501-5969...
- Page 2 WARNINGS / LIMITATIONS • Fits 20-29" wheels up to 3" wide. • 4 Bike maximum carrying capacity = 180 lbs./80Kg. • Can work with bikes with fenders. • Not intended for off-road use. • Not intended for tandems or recumbents. •...
- Page 3 17 mm Tighten Well 1/2" 13mm (not included) Tighten Well 501-5969...
- Page 4 FOOT INSTALLATION FOR 2" RECEIVERS 3/4" ¾ po 1,9 cm Receiver Installation Tighten Well THE RACK IS NOW READY TO LOAD BIKES. 501-5969...
- Page 5 • Raise the hooks by depressing the grey buttons and sliding the hooks upward on the mast. Bicycle Installation • Place the bike on the bike tray with the wheels in the wheel trays and push down hook firmly until top tube fits snug against top bend of hook underside.
- Page 6 Tighten Well • ALWAYS POSITION SMALLER BICYCLE BETWEEN THE BICYCLE SUPPORT AND THE CAR BUMPER. THE • Attach wheel straps to front and rear wheels as BUYER SHOULD BE AWARE THAT THE COMBINED WEIGHT OF THE BICYCLE CARRIER (26 lbs/11.8 kg) shown.
