Summary of Contents for Vela Latin 100
- Page 1 U S E R M A N U A L VELA Latin 100/200/300 VARIANT: Manual no. 105378 VELA Latin 100 VELA Latin 200 VELA Latin 300...
-
Page 2: Table Of Contents
1.9.2. Adjustment of seat height with foot ring 1.9.3. Adjustment of seat height with lever 1.9.4. Adjustment of seat tilt 1.9.5. Adjustment of back height 1.9.6. Adjustment of back tilt 1.9.7. Back latch (VELA Latin 200) 1.9.8. armrest (optional) 1.9.9. Footrest ring (optional) -
Page 3: Introduction
1.0. INTRODUCTION DEAR CUSTOMER Congratulations on your new VELA chair! We are sure this chair will give you daily pleasure. This user manual provides useful information on adjusting, operating and maintaining your chair. Important Please read this user manual carefully and keep it safe for when you need to refer to it. -
Page 4: Warnings
1.1. WARNINGS In case of an allergic reaction, stop using the chair and consult a doctor Only use original spare parts from VELA Do not make any changes to the accessories that come with the chair Only use the chair for the intended purpose Only adjust the seat angle while the user’s feet are on the floor... -
Page 5: Troubleshooting
Contact your VELA supplier The chair rolls badly Wheels are blocked. Clean the wheels for wire residue and the like. If the above does not solve your problem, you should contact your VELA supplier. -
Page 6: Labels Used On The Chair
IN GENERAL 1.3. LABELS USED ON THE CHAIR Warning Risk of shear and squeeze: Keep hands and fingers away from moving parts Icon Read ”Instruction For Use” before use Icon Part used: Type B cf. IEC60601-1 covering the following areas of the chair: Labels <Model name>... -
Page 7: Safety
VELA supplier right away. In such cases, do not attempt to use the chair or to fix it yourself. 1.5. WARRANTY VELA grants a right of claim under applicable law in the country where the chair is acquired. The right of... -
Page 8: Maintenance
On delivery you have received: 1.7.4. RECYCLING GUIDE Your VELA chair can be reused by :: VELA chair another person when you no longer need it as long as the chair is servi- :: Instructions for use ced by a technician beforehand. -
Page 9: User Manual
1.9. USER MANUAL Replacement of the gas spring may only be performed by the service support team from your dealer or a skilled technical person. 1.9.1. ATTACHING THE BACKREST The lever for backrest adjustment (1) must be in open position. Press the locking pin spring (2) and push the backrest arm through the hole. -
Page 10: Adjustment Of Back Height
Adjust the back tilt by pushing the rear lever placed at your right hand. 1.9.7. BACK LATCH (VELA LATIN 200) The backrest can be set to a specific angle by adjusting and secure the the bolt which is mounted on the rear side of the VELA backrest. -
Page 11: Footrest Ring (Optional)
1.9.9. FOOTREST RING (OPTIONAL) A 45 cm footrest ring, adjustable in height. The footrest ring provides stability, support and comfort in the sitting position. A footrest ring is especially practical when the user is sitting high... - Page 12 VELA :: Gøteborgvej 8-12 :: 9200 Aalborg SV :: Denmark :: +45 96 34 76 00 :: mail@vela.dk...
