Parts List - Icom IC-M803 Service Manual

SECTION 6
[MAIN UNIT]
REF PART
NO. NO.
IC4001 1110008540 S.IC 62783G-S18-R
IC4002 1110008540 S.IC 62783G-S18-R
IC4021 1110008550 S.IC NJM2904CRB1-TE1-#HMZR
IC4022 1110008550 S.IC NJM2904CRB1-TE1-#HMZR
IC4051 1130018870 S.IC TC7WH14FKLJ
IC4061 1110006921 S.IC S-80845CNMC-B86T2G
IC4071 1130018870 S.IC TC7WH14FKLJ
IC4072 1110005140 S.IC NJM3403AV-TE1-#ZZZB
IC4261 6910027620 S.DC TPS54418RTER
IC4262 1130007021 S.IC TC7S66FU (TE85LF)
IC4321 1180004970 S.REG XC6222D251MR-G
IC4331 1180004740 S.REG S-1313D33-M5T1U3
IC4341 1180004740 S.REG S-1313D33-M5T1U3
IC4361 1180004430 S.REG XC6209F502MR-G
IC4371 1180004800 S.REG XC6222D181MR-G
IC4381 6910028150 S.DC ADP5075ACBZ-R7
IC4401 1110007400 S.IC BGA616
IC4661 1110007400 S.IC BGA616
IC4662 1180004430 S.REG XC6209F502MR-G
IC4901 1140018901 S.IC STM32F429IGT6
IC4902 1130018050 S.IC SN74AHCT367PWR
IC5001 1130019460 S.IC GT24C256A-2ZLI-TR
IC5011 1110005771 S.IC S-80942CNMC-G9CT2G
IC5051 1130016460 S.IC R2A20169SA
IC5061 1130017400 S.IC MC74HC4094ADTR2G
IC5062 1130017400 S.IC MC74HC4094ADTR2G
IC5063 1130017400 S.IC MC74HC4094ADTR2G
IC5064 1130017400 S.IC MC74HC4094ADTR2G
IC5081 1130011551 S.IC RX-4581NB-F
IC5101 1140018370 S.IC 5CEFA9F23I7N
IC5102 6910024650 S.IC 74LVC2G17GW125
IC5103 6910024650 S.IC 74LVC2G17GW125
IC5104 1130018770 S.IC S25FL127SABMFI100
IC5161 1180004430 S.REG XC6209F502MR-G
IC5181 1110009190 S.IC LTC6401IUD-20#TRPBF
IC5201 1190005200 S.IC AD9645BCPZRL7-80
IC5241 1110009190 S.IC LTC6401IUD-20#TRPBF
IC5281 1190004630 S.IC ISL5961IAZ
IC5401 1130019760 S.IC IPS6404L-SQ-SPN
IC5441 1130012160 S.IC SN74LVC1GU04DCKR
IC5451 1130017950 S.IC SN65LVDS1DBVR
IC5461 1130014260 S.IC SN74LVC2GU04DCKR
IC5491 1130012160 S.IC SN74LVC1GU04DCKR
IC5501 1110007930 S.IC PCM1681PWPR
IC5502 1110008890 S.IC NJU7056F3-TE2-#ZZZH
IC5521 1110006570 S.IC TS462CPT
IC5541 1110004050 S.IC NJM3404AV-TE1-#FMZB
IC5561 1110008550 S.IC NJM2904CRB1-TE1-#HMZR
IC5581 1110008550 S.IC NJM2904CRB1-TE1-#HMZR
IC5601 1110009480 IC STA540-HF
IC5621 1190004280 S.IC PCM1802DBR
IC5651 1130009981 S.IC TC7W53FK (TE85LF)
IC5661 1130009981 S.IC TC7W53FK (TE85LF)
IC5681 1130009981 S.IC TC7W53FK (TE85LF)
IC5911 1110005610 S.IC NJM2058V-TE1-#ZZZB
IC5921 1110005610 S.IC NJM2058V-TE1-#ZZZB
Q4021 1590005220 S.TRA LDTA114YET1G
Q4022 1590004690 S.TRA LDTC143ZET1G
Q4023 1590004690 S.TRA LDTC143ZET1G
Q4061 1530004140 S.TRA L2SC4081RT1G
Q4062 1590005220 S.TRA LDTA114YET1G
Q4063 1550000241 S.FET TPCF8107LF
Q4071 1590004690 S.TRA LDTC143ZET1G
Q4072 1590005220 S.TRA LDTA114YET1G
Q4073 1530004140 S.TRA L2SC4081RT1G
Q4141 1530004140 S.TRA L2SC4081RT1G
Q4142 1530004140 S.TRA L2SC4081RT1G
Q4161 1590005220 S.TRA LDTA114YET1G
Q4162 1530004620 S.TRA 2SCR553P5T100
Q4341 1560002210 S.FET RE1J002YNTCL
Q4342 1590005220 S.TRA LDTA114YET1G
Q4401 1590005220 S.TRA LDTA114YET1G
Q4402 1590004690 S.TRA LDTC143ZET1G
Q4421 1530003091 S.TRA 2SC4213-B (TE85RF)
Q4422 1590005220 S.TRA LDTA114YET1G
Q4423 1590004690 S.TRA LDTC143ZET1G
Q4424 1590004690 S.TRA LDTC143ZET1G
Q4426 1590004690 S.TRA LDTC143ZET1G
Q4427 1590005220 S.TRA LDTA114YET1G
Q4631 1590005220 S.TRA LDTA114YET1G
Q4632 1590004690 S.TRA LDTC143ZET1G
Q4641 1530004560 S.TRA 2SC3356G-B-AE2-R
Q4642 1590005220 S.TRA LDTA114YET1G
Q4643 1590005220 S.TRA LDTA114YET1G
Q4644 1590004690 S.TRA LDTC143ZET1G
Q4661 1590005220 S.TRA LDTA114YET1G
Q4662 1590005220 S.TRA LDTA114YET1G
Q4663 1590004690 S.TRA LDTC143ZET1G
Q4701 1590004690 S.TRA LDTC143ZET1G
Q4702 1530004140 S.TRA L2SC4081RT1G
Q4871 1590005220 S.TRA LDTA114YET1G
Q4872 1590004690 S.TRA LDTC143ZET1G
Q4881 1530004560 S.TRA 2SC3356G-B-AE2-R
Q4882 1590005220 S.TRA LDTA114YET1G
Q4883 1590005220 S.TRA LDTA114YET1G
Q4884 1590004690 S.TRA LDTC143ZET1G
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.

PARTS LIST

DESCRIPTION M.
LOCATION
T 130.5/111.3
T 118.3/111.8
T 107.6/109.1
T 107.6/104.3
T
T 176.8/102.7
T 188.1/104.4
T 156.7/101.2
T 179.4/70.4
T 183.1/82.6
T 174.6/87.0
T 180.0/92.6
T 174.6/91.9
T 117.6/18.5
T 184.2/92.6
T 115.9/12.5
T
T 73.5/49.8
T 105.1/44.6
T 177.2/45.5
T 151.4/40.2
T 173.9/25.2
T 191.4/23.0
T 144.5/102.0
T 131.9/100.8
T
T 79.2/86.2
T 72.5/115.5
T 205.9/45.7
T 144.6/77.0
T 202.5/108.4
T 198.2/108.4
T 214.9/57.2
T 94.3/103.2
T 105.5/80.3
T 125.2/85.9
T 105.7/91.8
T 123.7/69.7
T 145.1/55.3
T 117.8/54.4
T 116.4/58.8
T 123.4/58.5
T 123.9/54.4
T 88.8/32.6
T 56.3/24.5
T
T 133.8/6.4
T 112.6/49.5
T 105.3/60.6
T
T 58.2/18.5
T 178.5/16.0
T
T 204.6/89.7
T 195.7/89.7
T 123.1/100.3
T 125.6/100.3
T 125.6/98.2
T 179.9/103.0
T 176.9/110.9
T 177.9/107.4
T 183.9/104.9
T 183.9/107.5
T 165.2/101.7
T 143.5/10.2
T 175.2/11.4
T 146.3/10.1
T 146.5/6.6
T 170.4/81.9
T 175.0/94.8
T 19.2/54.7
T 19.2/52.2
T
T
T
T 15.0/52.2
T
T
T 106.1/51.5
T 106.1/48.9
T 73.5/68.2
T 100.9/54.5
T 106.1/54.5
T 104.1/54.5
T 104.1/51.5
T 100.8/51.5
T 104.1/48.9
T
T 13.9/96.3
T 113.3/97.8
T 116.9/97.8
T 80.5/109.0
T 113.3/93.3
T 113.3/95.3
T 116.9/95.3
[MAIN UNIT]
H/V REF PART
NO. NO.
Q5041 1590004690 S.TRA
Q5042 1530004140 S.TRA
Q5081 1510000502 S.TRA
Q5082 1530004140 S.TRA
99.8/27.2 Q5421 1530004590 S.TRA
Q5422 1510001270 S.TRA
Q5481 1530004590 S.TRA
Q5482 1510001270 S.TRA
Q5581 1530004140 S.TRA
Q5582 1530004140 S.TRA
Q5651 1590004690 S.TRA
Q5661 1590004690 S.TRA
Q5681 1590004690 S.TRA
Q5901 1590005220 S.TRA
Q5902 1550000610 S.FET
Q5911 1530004140 S.TRA
4.8/82.1 Q5931 1590005220 S.TRA
Q5932 1590004690 S.TRA
Q5981 1510001270 S.TRA
D4021 1750001810 S.DIO
D4023 1750001820 S.DIO
D4024 1750001820 S.DIO
D4035 1750001810 S.DIO
68.7/84.4 D4071 1750001820 S.DIO
D4072 1750001820 S.DIO
D4074 1750001820 S.DIO
D4101 1750001820 S.DIO
D4102 1750001820 S.DIO
D4103 1750001820 S.DIO
D4141 1750001810 S.DIO
D4142 1750001810 S.DIO
D4383 1750002110 S.DIO
D4401 1790001622 S.DIO
D4421 1790001622 S.DIO
D4434 1750003040 S.DIO
D4435 1750003040 S.DIO
D4451 1790001622 S.DIO
D4452 1790001622 S.DIO
D4471 1790001622 S.DIO
D4472 1790001622 S.DIO
D4491 1790001622 S.DIO
D4492 1790001622 S.DIO
D4511 1790001622 S.DIO
56.9/37.4 D4512 1790001622 S.DIO
D4531 1790001622 S.DIO
D4532 1790001622 S.DIO
D4551 1790001622 S.DIO
D4552 1790001622 S.DIO
73.1/32.5 D4571 1790001622 S.DIO
D4572 1790001622 S.DIO
D4591 1790001622 S.DIO
58.2/11.8 D4592 1790001622 S.DIO
D4611 1790001622 S.DIO
D4612 1790001622 S.DIO
D4631 1790001622 S.DIO
D4632 1790001622 S.DIO
D4641 1790001622 S.DIO
D4642 1790001622 S.DIO
D4643 1750001810 S.DIO
D4661 1790001622 S.DIO
D4662 1750003070 S.DIO
D4663 1750003070 S.DIO
D4664 1750003070 S.DIO
D4665 1750001810 S.DIO
D4666 1790001622 S.DIO
D4701 1750003040 S.DIO
D4702 1750003040 S.DIO
D4703 1750001820 S.DIO
D4704 1750001810 S.DIO
D4731 1790001622 S.DIO
D4732 1790001622 S.DIO
D4751 1790001622 S.DIO
D4752 1790001622 S.DIO
10.4/57.0 D4771 1790001622 S.DIO
17.1/54.7 D4772 1790001622 S.DIO
15.0/54.7 D4791 1790001622 S.DIO
D4792 1790001622 S.DIO
21.3/52.2 D4811 1790001622 S.DIO
21.3/54.7 D4812 1790001622 S.DIO
D4841 1790001622 S.DIO
D4842 1790001622 S.DIO
D4871 1790001622 S.DIO
D4872 1790001622 S.DIO
D4881 1790001622 S.DIO
D4882 1750001810 S.DIO
D4883 1790001622 S.DIO
D5071 1750003410 S.ZEN
D5081 1750001810 S.DIO
12.7/99.0 D5161 1750003070 S.DIO
D5221 1750003070 S.DIO
D5901 1750001810 S.DIO
D5921 1750001810 S.DIO
D5941 1750001810 S.DIO
D5951 1750001810 S.DIO
D5961 1750001810 S.DIO
D5962 1750001810 S.DIO
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
6-1
DESCRIPTION M.
LDTC143ZET1G T
L2SC4081RT1G T
2SA1162-GRLF T
L2SC4081RT1G T
BFR193F H6327 T
2SAR502UBTL T
BFR193F H6327 T
2SAR502UBTL T
L2SC4081RT1G T
L2SC4081RT1G T
LDTC143ZET1G T
LDTC143ZET1G T
LDTC143ZET1G T
LDTA114YET1G T
RU1L002SNTL T
L2SC4081RT1G T
LDTA114YET1G T
LDTC143ZET1G T
2SAR502UBTL T
L1SS400T1G T
LRB706F-40T1G T
LRB706F-40T1G T
L1SS400T1G T
LRB706F-40T1G T
LRB706F-40T1G T
LRB706F-40T1G T
LRB706F-40T1G T
LRB706F-40T1G T
LRB706F-40T1G T
L1SS400T1G T
L1SS400T1G T
LRB551V-30T1G T
1SV308L3F T
1SV308L3F T
L709CEAR T
L709CEAR T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
L1SS400T1G T
1SV308L3F T
BAP70Q T
BAP70Q T
BAP70Q T
L1SS400T1G T
1SV308L3F T
L709CEAR T
L709CEAR T
LRB706F-40T1G T
L1SS400T1G T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
1SV308L3F T
L1SS400T1G T
1SV308L3F T
RCLAMP7524T.TNT T
L1SS400T1G T
BAP70Q T
BAP70Q T
L1SS400T1G T
L1SS400T1G T
L1SS400T1G T
L1SS400T1G T
L1SS400T1G T
L1SS400T1G T
