- Page 1 BED - BURLEIGH Assembly Instructions - Please keep for future reference Important - Please read these instructions fully before starting assembly...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on We do not Check you have all the the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Arrow indicate finished face Left Side Rail - 1 Pc Head Board - 1 Pc Foot Board - 1 Pc Right Side Rail - 1 Pc 3 Holes Horizontal Rail x 3 Pcs Center Support x 1 Pc Support Leg x 3 Pcs...
-
Page 4: Exploded View
Exploded View Page 3... - Page 5 Assembly Instructions Step 1 Connect the head board and foot board to the both side rail Secure the left side rail 3 in place with "L" key D Detail-A Repeat on the right side rail 4 and foot board 2 Detail-A Step 2 Connect the 3 holes...
- Page 6 Assembly Instructions Step 3 Connect the 3 holes horizontal rail to both side rail Secure the 3 holes horizontal rail 5 in place with screw C Detail-C Repeat on the other 3 holes horizontal rail 5 Detail-C Step 4 Connect the 2 holes horizontal rail to both side rail Secure the 2 holes horizontal...
- Page 7 Congratulation! Your unit is complete. Notes Page 6...
