3 Door Robe
Assembly Instructions
001 xx 7494
- Please keep for future reference
Dimensions
Width - 100.9cm
Depth - 49.8cm
Height - 180.0cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 29/05/17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for J D Williams 001 7494 Series
Summary of Contents for J D Williams 001 7494 Series
- Page 1 3 Door Robe Assembly Instructions 001 xx 7494 - Please keep for future reference Dimensions Width - 100.9cm Depth - 49.8cm Height - 180.0cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 0847 (100.9x49.8cm) 0848 Bottom (97.5x46.4cm) 0851 Plinth x 2 (97.5x7.6cm) 0849 0844 0845 Divider Left End Panel Right End Panel (169.1x46.4cm) (178.4x49.6cm) (178.4x49.6cm) 0677...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534 123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 0847 7200 7194 0844 0852 0673 0850 0846 0849 0677 0846 0846 0845 0848 0851... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 6 metal dowels into the top panel 0847 Note: Tighten metal 0847 dowels up fully against the panel. Do not over-tighten. Step 2 Connect the top rail to the top panel. 7200 Using 4 screws secure...
- Page 7 Assembly Instructions Correct Step 5 Attach hinges to the 3 doors Incorrect Insert hinges into holes, ensure the hinge is straight (90 degree angle). 0846 Bradawl Before securing the hinges , we recommend you pre - mark the doors using a bradawl. 0846 Secure hinges doors using screws...
- Page 8 Assembly Instructions Step 6 Fitting hanging rail support & hingeplates to left end. Insert 3 hinge plates into the left end panel 0844 Insert 2 screws through the holes in the hanging rail support Note: A bradawl may be required when attaching 0844 the hanging rail support to create the lower hole.
- Page 9 Assembly Instructions Step 8 Fitting hanging rail support & hingeplates to right end. Insert 3 hinge plates into the right end panel 0845 0845 Insert 2 screws through the holes in the hanging rail supports Note: A bradawl may be required when attaching the hanging rail support to create the lower hole.
- Page 10 Assembly Instructions Step 11 Attach hanging rail support and cams to the divider panel. Insert 2 metal cams into the divider panel 0849 Secure the hanging rail 0849 support bracket with 2 screws Step 12 Attach dowels and hinge plates. Insert 2 metal dowels 0849 and 3 hingeplates...
- Page 11 Assembly Instructions Step 14 Connect the right end panel to the bottom, and small shelf. Connect the dowels in 0845 0845 the right end panel to the cams in the bottom 0848 and the small shelf 0850 0850 Turn cams 180 degrees clockwise to lock.
- Page 12 Assembly Instructions Step 17 Connect the large shelf, & back rail to the divider panel. Connect the plinths to the Rh end . We recommend that an additional person is used to support the plinth panels during this stage 0673 0845 and the next stage.
- Page 13 Assembly Instructions Step 19 Connect the top panel to the divider and the end panels. Connect the dowels in the 0847 top panel to the cams in the left end 0844 0849 , divider 0847 the right end panel 0845 0845 0849 0844...
- Page 14 Assembly Instructions Step 21 Squaring up the unit. IMPORTANT! Ensure a tape measure is used 9143 to square unit up. 8588 Before securing the back it is necessary to square up the unit. Make sure that the back panel is still sat in the grooves.
- Page 15 Assembly Instructions Step 23 Add stability blocks. Slide the thin point of the stability blocks between the back panel 0852 and the grooves. Once inserted fully, tighten the screws in the stability blocks. 9143 8588 0852 8589...
- Page 16 Assembly Instructions Step 24 IMPORTANT! Fixing to wall We recommend that this This unit must be secured to the unit is fixed to a suitable wall prior to fitting the doors. wall to prevent possible overbalancing. We have Failure to do this could make the unit included a fixing bracket unstable and potentially dangerous for this.
- Page 17 Assembly Instructions Step 26 Hanging doors With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. See Diagrams 1, 2 and 3. 9874 0846 Tighten screw shown to lock hinges in 0049 position.
- Page 18 Assembly Instructions Step 27 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
- Page 19 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
- Page 20 Notes; ENTER PAGE NUMBER...
