2 Door Hideaway
Assembly Instructions
024 xx 9431
- Please keep for future reference
Dimensions
Width - 82.8cm
Depth - 48.8cm
Height - 74.8cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 14/05/19
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for J D Williams Langley Hideaway desk
Summary of Contents for J D Williams Langley Hideaway desk
- Page 1 2 Door Hideaway Assembly Instructions 024 xx 9431 - Please keep for future reference Dimensions Width - 82.8cm Depth - 48.8cm Height - 74.8cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 9188 8172 Bottom (82.8x48.8cm) (79.4x45.1cm) 1363 1364 Left End Panel Right End Panel 8171 (73.2x48.6cm) (73.2x48.6cm) Plinth (79.4x6.0cm) 8174 Backrail (79.4x29.0cm) 8175 Shelf (54.4x33.7cm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some cases more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 9188 8174 1363 1365 8175 8172 8176 1364 1366 8171 1366... - Page 6 Assembly Instructions Step 1 Fitting cams to the bottom panel. Insert 4 metal cams into the bottom panel 8172 8172 Note: Ensure cam arrow points towards the edge with the hole. Step 2 Fitting cams to the back rail. Insert 4 metal cams into the back rail panel 8174 8174...
- Page 7 Assembly Instructions Step 5 Correct Attach hinges and handles to the doors Incorrect Insert hinges into holes, ensure the hinge is straight (90 degree angle). 1366 Bradawl Before securing the hinges , we recommend you pre - mark the doors using a bradawl.
- Page 8 Assembly Instructions Step 6 Fitting cams and dowels to shelf panel. Insert 2 metal dowels and 2 cams into the 8175 shelf panel 8175 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 7 Fitting dowels, cams and hinge plates to the left end panel.
- Page 9 Assembly Instructions Step 9 Diagram 1 Attaching the left bracket to the left end. Using 2 screws secure the bracket the left end panel 1363 as shown in diagram 1. 1363 Diagram 2 Use 1 screw secure the front of the bracket.
- Page 10 Assembly Instructions Step 11 Fitting dowels to the top panel. Insert 4 metal dowels into the top panel 9188 9188 Step 12 Connect LH and RH runners to the shelf panel. Using 6 screws secure the left runner and the right runner 1365 to the shelf Ensure that the wheel on...
- Page 11 Assembly Instructions Step 14 Connect the divider panel to the shelf panel. Connect the dowels in the 8176 8175 shelf panel to the cams in the divider panel 8176 8175 Turn cams 180 degrees to lock. Step 15 Connect the left end panel to the bottom panel.
- Page 12 Assembly Instructions Step 17 Connect the plinth panel to the left end. Connect the metal dowel in the left end panel 1363 to the cam in the plinth 8171 panel and insert the wooden dowel into the pre-drilled hole. IMPORTANT! 1363 8171 An additional person...
- Page 13 Assembly Instructions Step 19 Attaching top panel 9188 Connect the metal dowel 9188 in the top panel the cams in the LH end 1363 and RH end 1364 1363 Turn cams 180 degrees to lock. 1364 Step 20 Hanging doors With help, slot door hinges onto hinge plates.
- Page 14 Assembly Instructions Step 21 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
- Page 15 Assembly Instructions Step 22 Fit the shelf. 1365 Tilt the shelf shown and slide onto the runner brackets. 1365...
- Page 16 Assembly Instructions Step 23 WARNING Fixing to wall We recommend that this IN ORDER TO PREVENT OVERTURNING THIS PRODUCT MUST BE USED WITH unit is fixed to a suitable THE WALL ATTACHMENT DEVICE wall to prevent possible PROVIDED overbalancing. We have Serious or fatal crushing injuries can occur from included a fixing bracket furniture tipping over.
- Page 17 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
- Page 18 Notes;...
- Page 19 Notes;...
- Page 20 Notes;...
