Tamerica TCC-1200 Operating Manual

45” wide format hot and cold laminator
Hide thumbs Also See for TCC-1200:
Table of Contents

Advertisement

Quick Links

Download this manual
Roll Laminator
Operating Manual
TCC-1200
45" Wide Format Hot and Cold Laminator

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCC-1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Tamerica TCC-1200

Summary of Contents for Tamerica TCC-1200

  • Page 1 Roll Laminator Operating Manual TCC-1200 45” Wide Format Hot and Cold Laminator...

  • Page 2: Important Safeguards

    OPERATING INSTRUCTIONS TCC1200 1 IMPORTANT SAFEGUARDS When using electrical machines, basic precautions should always be followed to reduce the risk of electric shock and injury to people, including the following: 1. Read all instructions. 2. Please note that this machine runs on 220V/60Hz with a rated current requirement of 12A~14A and comes with a single phase NEMA L6-20 AC plug.

  • Page 3: Machine Operation

    3 MACHINE OPERATION A. LAMINATING FUNCTION (1) TWO-SIDED LAMINATION LOADING THE FILM This machine has the capability of loading laminating film with 1” cores or with 3” cores using the included core adapters. Unpack the upper and lower rods. Remove the feed tray.
  • Page 4 ADJUSTING THE TEMPERATURE & SPEED 1. User should set up the temperature for upper and lower rollers separately. Turn on the power switch and press the “U” key, then the digital screen display will show the previous temperature setting of upper ︿...
  • Page 5 (2) ONE-SIDED LAMINATION LOADING THE FILM Unpack only the upper rod. Install nylon, BOPP or even thermal film on 1” or 3” core by following an adapter---film---adapter sequence onto the rod and fit the adapters onto the paper core. Leave equal lengths of the rod out of each end.

  • Page 6: Cold Lamination

    2. Push the film through the rollers with a threading card and make sure the film is correctly threaded based on the threading guide. ADJUSTING THE TEMPERATURE & SPEED 1. Turn on the power switch and make sure to turn off the “BOTTOM ROLLER HEATER” switch on the right side of machine.
  • Page 7 of film then tighten the screw on the adapter to secure the roll film. Load the rods on the laminator and adjust accordingly to make sure the film and the kraft paper are aligned. THREADING THE FILM Read the threading card supplied with each roll of film carefully. Do not mistake the stabilizer bar for the idler roller.

  • Page 8: Foot Pedal Operation

    ADJUSTING THE TEMPERATURE & SPEED 1. Turn the machine on. The power switch and the control panel will light up. 2. Set the machine’s temperature and then set the desired speed. (Please refer to "ADJUSTING THE TEMPERATURE & SPEED" in previous page.) LAMINATING PROCEDURES 1.
  • Page 9 C. SAFETY SHIELD AND FEED TRAY SENSORS Both the safety shield and feed tray activate sensors that allow the bottom roller to feed film when they are properly installed. Removal or misalignment of either or both of these items will cause the LED light to turn on and stop the rollers from feeding even when rollers are engaged.
  • Page 10 the board, carefully and evenly align the print and set it onto the adhesive side. The pressure applied by the rollers will enhance adhesion of the print onto the board. Please refer to instructions on how to apply prints on these types of boards that come with their packaging or consult with the mounting board supplier.

  • Page 11: Auto Shut-Off Function

    H. AUTO SHUT-OFF FUNCTION This machine is equipped with an auto shutoff feature. When using the machine with this feature, turn on the Auto Shutoff Switch found on the left side panel. The following is a step by step diagram of its operation: CONTROL PROCESS FOR AUTO SHUT OFF USER DISENGAGES ROLLERS...

  • Page 12: Emergency Stop Buttons

    I. FILM SLITTER This machine is equipped with safety film slitter in the back of the machine for trimming film in between sheets of laminated material. Simply slide the cutting edge across the film to remove the finished material. J. EMERGENCY STOP BUTTONS In case of emergencies, press either front or back red emergency buttons to immediately stop the motor and turn off the machine.

  • Page 13: Warranty

    This machine is guaranteed against defects in materials and workmanship by the Manufacturer for a period of one (1) year from the date of original purchase from an authorized distributor of Tamerica Products, Inc. If you perceive or experience any issue with the machine, kindly report it to the distributor within 10 business days of said purchase to avail of free pickup and redelivery from Tamerica’s Service Center.
