Tamerica Versalam 2700-P Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Roll Laminator
Operating Manual
Versalam2700-P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Versalam 2700-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tamerica Versalam 2700-P

Summary of Contents for Tamerica Versalam 2700-P

  • Page 1 Roll Laminator Operating Manual Versalam2700-P...

  • Page 2: Important Safeguards

    OPERATING INSTRUCTIONS Versalam2700P 1 IMPORTANT SAFEGUARDS When using electrical machines, basic precautions should always be followed to reduce the risk of electric shock and injury to people, including the following: 1. Read all instructions. 2. Always unplug the machine when not in use or before cleaning. 3.

  • Page 3: Machine Operation

    3 MACHINE OPERATION A. LAMINATING FUNCTION (1) TWO-SIDED LAMINATION LOADING THE FILM This machine has the capability of loading laminating film with 1” cores or with 3” cores using the included core adapters. Unpack the upper and lower rods. Remove the feed tray.
  • Page 4 ADJUSTING THE TEMPERATURE & SPEED User should set up the temperature for upper and lower rollers separately. Turn on the power switch and press the “U” key, then the digital screen display will show the previous temperature setting of upper roller. Please adjust the temperature to the recommended setting based on the thickness of ︿...
  • Page 5 Film Thickness Temperature Speed 1.5 Mil (38 Micron) 110°C (230°F) 3 Mil (75 Micron) 110°C (230°F) 5 Mil (125 Micron) 125°C (257°F) 10 Mil (250 Micron) 135°C (275°F) LAMINATING PROCEDURES 1. Push the handle to “DOWN” position to engage the rollers. Make sure the motor switch is in “RUN”...
  • Page 6 ADJUSTING THE TEMPERATURE & SPEED 1. Turn off the “BOTTOM ROLLER HEATER” switch on the right side of machine. 2. Press the “U” key and the digital screen display will show the previous temperature setting of upper ︿ ﹀ roller. Adjust the upper roller temperature by pressing the “TEMP/SET” “ ”...

  • Page 7: Temperature Conversion

    B. TEMPERATURE CONVERSION This machine can display temperatures in either Celsius or Fahrenheit. To change to either one, simply press and hold the “TEMP/SET” arrow keys simultaneously. C. GUIDE PLATES This machine is equipped with guide plates on the left and right sides of the feed tray for proper alignment of materials to be laminated.
  • Page 8 print is properly aligned onto the board. c. For cold mounting only using self stick boards that have liners, care and precision must be exercised as this has a tendency to produce wrinkles and/or uneven positioning when the print is not properly set.
  • Page 9 MOUNTING WITHOUT LAMINATION F. FILM SLITTERS This machine is equipped with safety film slitters in the back for trimming film in between sheets of laminated material. The short slitter is for 2-side laminated film while the longer slitter is for 1-side laminated material.

  • Page 10: Care And Cleaning

    This machine is guaranteed against defects in materials and workmanship by the Manufacturer for a period of one (1) year from the date of original purchase from an authorized distributor of Tamerica Products, Inc. If you perceive or experience any issue with the machine, kindly report it to the distributor within 10 business days of said purchase to avail of free pickup and redelivery from Tamerica’s Service Center.
  • Page 11 This warranty expresses the entire obligation of the Manufacturer. Unless prohibited by law, neither this warranty nor any other warranty expressed or implied, including implied warranties of merchantability, shall extend this warranty period. Again, no responsibility is assured for incidental or consequential damages.
