- Page 1 Roll Laminator Operating Manual Versalam-1300/ 2700EP...
-
Page 2: Important Safeguards
OPERATING INSTRUCTIONS 1 IMPORTANT SAFEGUARDS When using electrical machines, basic precautions should always be followed to reduce the risk of electric shock and injury to people, including the following: 1. Read all instructions. 2. Always unplug the machine when not in use or before cleaning. 3. -
Page 3: Machine Operation
3 MACHINE OPERATION A. LAMINATING FUNCTION (1) TWO-SIDED LAMINATION LOADING THE FILM This machine has the capability of loading laminating film with 1” cores or with 3” cores using the included core adapters. Unpack the upper and lower rods. Remove the feed tray. - Page 4 ADJUSTING THE TEMPERATURE & SPEED 1. User should set up the temperature for upper and lower rollers separately. Turn on the power switch and press the “U” key, then the digital screen display will show the previous temperature setting of upper roller.
- Page 5 Film Thickness Temperature Speed 1.5 Mil (38 Micron) Normal 120°C (248°F) 1.5 Mil (38 Micron) Max. Output 135°C (275°F) 3 Mil (75 Micron) Normal 120°C (248°F) 3 Mil (75 Micron) Max. Output 130°C (266°F) 5 Mil (125 Micron) 135°C (275°F) 10 Mil (250 Micron) 140°C (284°F) LAMINATING PROCEDURES...
- Page 6 ADJUSTING THE TEMPERATURE & SPEED 1. Turn on the power switch and make sure to turn off the “BOTTOM ROLLER HEATER” switch on the right side of machine. 2. Press the “U” key and the digital screen display will show the previous temperature setting of upper ︿...
- Page 7 2. To put the lamination temporarily on hold without turning off the machine, user can turn the motor control switch to “STOP” position. This will cause the motor to stop running and the film will stop feeding. 3. To resume the lamination job, set the switch to “RUN” position again. B.
-
Page 8: Auto Shut-Off Function
H. AUTO SHUT-OFF FUNCTION This machine is equipped with an auto shutoff feature with ON/OFF switch. When using the machine with this feature, turn on AUTO SHUTOFF switch found on the left side panel. The following is a step by step diagram of its operation: CONTROL PROCESS FOR AUTO SHUT OFF USER DISENGAGES ROLLERS STAGE 1... - Page 9 I. MOUNTING FUNCTION 1. The user can choose to mount prints or posters using up to 1/4” thick foam boards. a. For mounting and encapsulating using thermal film, simply set the machine up for 2-SIDED LAMINATION. Line up the material evenly on a standard foam board and set the temperature of the machine.
-
Page 10: Care And Cleaning
MOUNTING WITH LAMINATION 4 TURNING OFF THE LAMINATOR Upon completion of the laminating job, please press the “COLD” key to turn off the heat and make sure the motor switch is in “STOP” position. We recommend turning off the machine only after the roller temperature is lower than 80°C (176°F) to protect the heated rollers. -
Page 11: Warranty
This machine is guaranteed against defects in materials and workmanship by the Manufacturer for a period of one (1) year from the date of original purchase from an authorized distributor of Tamerica Products, Inc. If you perceive or experience any issue with the machine, kindly report it to the distributor within 10 business days of said purchase to avail of free pickup and redelivery from Tamerica’s Service Center.
