Tamerica VERSALAM-2700HC Operating Manual

Roll laminator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Roll Laminator
Operating Manual
Versalam2700-HC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERSALAM-2700HC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tamerica VERSALAM-2700HC

Summary of Contents for Tamerica VERSALAM-2700HC

  • Page 1 Roll Laminator Operating Manual Versalam2700-HC...

  • Page 2: Important Safeguards

    1 IMPORTANT SAFEGUARDS When using electrical machines, basic precautions should always be followed to reduce the risk of electric shock and injury to people, including the following: 1. Read all instructions. 2. Always unplug the machine when not in use or before cleaning. 3.
  • Page 3 Note: you cannot interchange the upper and lower rods. Follow the color code. Orange with Orange color for top rolls and Blue to Blue for bottom rolls. THREADING THE FILM Read the threading card supplied with each roll of film carefully. Do not mistake the stabilizer bar for the idler roller.
  • Page 4 curl. If it curls up when it comes out of the machine, the top roll is likely tighter than the bottom. If it curls down, the bottom roll is likely tighter. To increase tension, turn the adjusting knob clockwise. To decrease tension, turn the knob counter clockwise. Even tension on the top and bottom rolls ensures flat lamination.
  • Page 5 (2) ONE-SIDED LAMINATION LOADING THE FILM Unpack only the upper rod. Install nylon, BOPP or even thermal film by following an adapter---film---adapter sequence onto the rod and fit the adapters onto the paper core. Leave equal lengths of the rod out of each end. Use the guide to position the roll of film then tighten the screw on the adapter to secure the roll film.

  • Page 6: Cold Lamination

    ADJUSTING THE TEMPERATURE & SPEED Turn on the power switch and make sure to turn off the “BOTTOM ROLLER HEATER” switch on the right side of machine. 2. Press the “U” key and the digital screen display will show the previous temperature setting of upper ︿...
  • Page 7 THREADING THE FILM Read the threading card supplied with each roll of film carefully. Do not mistake the stabilizer bar for the idler roller. 1. To thread the film through the “hot rollers” & “pull rollers”, please pull the handle to the “UP” position to release pressure on all the rollers.

  • Page 8: Temperature Conversion

    roller. Adjust the upper roller temperature by pressing the “TEMP/SET” “︿” or “﹀” arrow keys and press HOT key. 4. Once the set temperature is achieved and roller temperature is stabilized, the machine will start ︿ beeping and the ready light will turn on. Once the ready light stays on, press the “MOTOR” “ ”...

  • Page 9: Reverse Function

    E. REVERSE FUNCTION The machine is equipped with a reverse function. By pressing the “REVERSE” key, the machine will release the documents out from the front of the machine to prevent any jam or damage. F. FILM SLITTERS This machine is equipped with safety film slitters in the back of the machine for trimming film in between sheets of laminated material.
  • Page 10 3. Feed materials between the engaged rollers. 4. Put the motor switch in “STOP” position to stop the feeding when the board is all the way out in the back. MOUNTING WITHOUT LAMINATION MOUNTING WITH LAMINATION - 9 -...

  • Page 11: Auto Shut-Off Function

    I. AUTO SHUT-OFF FUNCTION This machine is equipped with an auto shutoff feature with ON/OFF switch. When using the machine with this feature, turn on AUTO SHUTOFF switch found on the left side panel. The following is a step by step diagram of its operation: CONTROL PROCESS FOR AUTO SHUT OFF USER DISENGAGES ROLLERS STAGE 1...

  • Page 12: Care And Cleaning

    This machine is guaranteed against defects in materials and workmanship by the Manufacturer for a period of one (1) year from the date of original purchase from an authorized distributor of Tamerica Products, Inc. If you perceive or experience any issue with the machine, kindly report it to the distributor within 10 business days of said purchase to avail of free pickup and redelivery from Tamerica’s Service Center.
  • Page 13 Removal or alteration of the serial number. The machine being serviced or modified by anyone other than a certified technician authorized by TAMERICA. This warranty expresses the entire obligation of the Manufacturer. Unless prohibited by law, neither this warranty nor any other warranty expressed or implied, including implied warranties of merchantability, shall extend this warranty period.
