Summary of Contents for Tamerica TCC-2700
- Page 1 TCC-2700 LAMINATOR 016-1 009-1 008-1 028-1 036-2...
- Page 2 TCC-2700 LAMINATOR Drawing No. Part No. Description Drawing No. Part No. Description RLM-25 CU BUSH RLM-1 RACKET RLM-26 PANNEL RACK RLM-2 FRONT ROLLER RLM-27 CONTROL PANNEL RLM-2A REAR ROLLER RLM-27-1 RLM-3 GUIDE PLATE RLM-28 AL PLATE RLM-4 FIXED PLATE RLM-29...
- Page 3 TCC-2700 LAMINATOR PART MANUAL 040-1 026-1...
- Page 4 TCC-2700 LAMINATOR PART MANUAL Drawing No. Part No. Description Drawing No. Part No. Description RLM-1 RACKET RLM-24 FIXED BUSH RLM-2 TOP ROLLER 028-1 RLM-24-1 FIXED BUSH RLM-2A BOTTOM ROLLER RLM-25 CU BUSH RLM-3 GUIDE PLATE 029-1 RLM-25-1 BUSH RLM-4 FIXED PLATE...
- Page 5 OPERATING INSTRUCTIONS TCC-2700 1. IMPORTANT SAFEGUARDS When using electrical appliances, basic precautions should always be followed to reduce the risk of electric shock and injury to people, including the following: Read all instructions. Always unplug the appliance when not in use or before cleaning.
- Page 6 HEAT & SPEED ADJUSTMENT TCC-2700 Turn on the power switch, the digital screen display will show the previous temperature setting. Please set the temperature to 90°C(l94F) to start the heat process. By pressing the "-.."or .. __. .. key of the "TEMP/SET", users can re-set the temperature. The lowest temperature this machine can be set is 90°C (194°F).
- Page 7 TENSION ADJUSTMENT Top and bottom supply rolls should have about the same tension. By turning the top roll with one hand, and the bottom roll with the other hand, it can be determined if one of the rolls is tighter than the other.
