ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-AC6802
DIFFICULT
Page 1 of 5
Tools Required for Assembly:
Allen Wrench
Phillips Screwdriver
(Included)
(Not Included)
Rev.14-03-27
Advertisement
Related Manuals for Furniture of America CM-AC6802
Summary of Contents for Furniture of America CM-AC6802
- Page 1 Assembly Instructions CM-AC6802 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 10 pcs Backrest Bolt #B x 10 pcs #2 x 1 pc Flat Washer Seat Frame...
- Page 4 Place the backrest (#1) on a protected surface. Align the right arm rest (#3) with the pre-drilled holes of the backrest (#1). III. Prepare 3 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B) onto the SAME bolt (#A), in that order.
- Page 5 Align the seat frame (#2) with the pre-drilled holes of the backrest (#1) and the right and left armrest Enlarged (#3 & #4). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B) onto the SAME #A x 4 pcs bolt (#A), in that order.
