For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-AC6562
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
Page 1 of 6
(Included)
(Not Included)
Rev:18-01-06
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-AC6562
Summary of Contents for Furniture of America CM-AC6562
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-AC6562 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 6pcs #1 x 1pc Bolt Ø1/4" x 2-3/8" Chair Back #B x 2pcs #2 x 2pcs Bolt Ø1/4"...
- Page 4 Exploded View 1) Insert barrel nuts (#G) to the holes of the stretchers (#5,6), then align stretchers (#5,6) to the holes of the legs (#4R/L). 2) Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#F) onto bolts (#A). Secure stretchers (#5,6) by tightening bolts (#A) onto barrel nuts (#G).
- Page 5 Align chair back (#1) to the holes of the seat (#3). Secure by using bolts (#C) with washers (#D,F). #C x 3pcs #D x 3pcs #F x 3pcs Align legs (#4R/L) to the holes of the seat, then secure by using bolts (#C) with washers (#D,F).
- Page 6 1) Align arms (#2R/L) to the holes of the chair back (#1) and seat (#3). Secure arms (#2R/L) to chair back (#1) by using bolts (#B) with washers (#D,F). Cover bolts (#A) by using caps (#I). #A x 2pcs #B x 2pcs #D x 4pcs #E x 2pcs #F x 2pcs...
- Page 7 E-commerce Division - Enitial Lab Thanhk you for your purchase! We hope you will enjoy your new product for many years to come to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
