MODEL #
CM-AC6801
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
Philips
Screwdriver
(Not Included)
2 - Persons
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Table of Contents
Related Manuals for Furniture of America Vaugh CM-AC680
Summary of Contents for Furniture of America Vaugh CM-AC680
- Page 1 MODEL # America Furniture CM-AC6801 Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 2 - Persons Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 7...
- Page 5 CHAIR CM-AC6801 Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS HARDWARE 5 / 7...
- Page 6 Place the backrest (#1) facing down on a protected surface. Align the right armrest (#3) with the pre-drilled holes of the backrest (#1). III. Prepare 3 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B) onto the SAME bolt (#A), in that order.
- Page 7 Part #2 x 1pc Align the chair seat (#2) with 9pcs Hardware #A x the pre-drilled holes of the Hardware x 9pcs backrest (#1), the right 9pcs Hardware #C x armrest (#3) and left armrest Hardware #D x (#4). Prepare 9 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B)
