Ergotron STYLEVIEW Quick Reference

RANGE OF MOTION
the following steps. Any time equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat
these adjustment steps to ensure safe and optimum operation. Adjustments should move smoothly and easily through the full range of motion and stay
where you set it. If adjustments are diffi cult and do not stay in the desired position, follow the instructions to loosen or tighten the tension to create a smooth,
easy adjustment motion. Depending on your product and the adjustment, it may take several turns to notice a diff erence.
20"
(508 mm)
14mm
NOTE: Adjustment may require
40 - 60 revolutions.
ERGONOMICS
Working
customize - to your size
1 Set top of monitor screen about one inch below eye level - Release brake
and lift or lower riser as needed.
2 Tilt screen for comfortable viewing and to reduce eye and neck strain.
3 Pull keyboard tray forward and position mouse tray and mouse pouch on
right or left, as needed.
4 Work with elbows bent at about 90° to minimize muscle strain.
5 If the riser moves up and down with diffi culty, or if it drifts out of set
position, consult the product
manual for adjustment
information.
6 Stay in charge!
Powered carts should be
plugged into outlet as often as
possible to keep battery charged
and computer running.
STYLEVIEW®
QUICK REFERENCE
For more information on this or other Ergotron products, visit our website: www.ergotron.com
It is important that you adjust this product according to the weight of the mounted equipment as described in
1
2
4
3
5
6
+ 12˚
25˚
Moving
stow - before you go
1 During normal movement, release brake and lower worksurface to
lowest position for optimal stability and unobstructed view.
2 Tuck away open trays and return mouse, scanner and other
accessories to their places.
3 Unlock both front casters.
4 Push cart from rear with elbows bent at about 90° to maximize
control and minimize muscle strain.
5 Don't run out!
Before moving, make
sure cord is unplugged
from outlet and hooked
to basket for safe travel.
Remember, charge
battery fully 100%
every day!
EN
12˚
5"
(127 mm)
10mm
1
4
5
3
777-24-006-G-00 rev.A • 08/10
