Ergotron STYLEVIEW Quick Reference

STYLEVIEW®
QUICK REFERENCE
RANGE OF MOTION
20"
(508 mm)
ERGONOMICS
Working
customize - to your size
1 Set top of monitor screen about one inch below eye level - Release brake
and lift or lower riser as needed.
2 Tilt screen for comfortable viewing and to reduce eye and neck strain.
3 Pull keyboard tray forward and position mouse tray and mouse pouch on
right or left, as needed.
4 Work with elbows bent at about 90° to minimize muscle strain.
5 If the riser moves up and down with diffi culty, or if it drifts out of set
position, consult the product
manual for adjustment
information.
6 Stay in charge!
Powered carts should be
plugged into outlet as often as
possible to keep battery charged
and computer running.
CAUTION! Completely release brake engagement
before raising or lowering the cart. Raising or
lowering the cart with the brake partially engaged
may cause product damage.
Wheel Rotation
1
2
4
3
5
12˚
180˚
Wheel Rotation and Swivel
Moving
stow - before you go
1 During normal movement, release brake and lower worksurface to
lowest position for optimal stability and unobstructed view.
2 Tuck away open trays and return mouse, scanner and other
accessories to their places.
3 Unlock both front casters.
4 Push cart from rear with elbows bent at about 90° to maximize
control and minimize muscle strain.
5 Don't run out!
Before moving, make
sure cord is unplugged
from outlet and hooked
to basket for safe travel.
Remember, charge
battery fully 100%
every day!
6
www.ergotron.com
USA: 1-800-888-8458
Europe: +31 (0)33-45 45 600
China: 400-120-3051
Japan: japansupport@ergotron.com
20˚
5˚
+ 12˚
Loosen knob, tilt Display
to desired position then
retighten knob.
5" (127 mm)
Locked
4
777-24-024-G-00 rev. E • 03/19
1
5
2
3
