Dalton Metal 3ft Frame
Assembly Instructions
656/9624
- Please keep for future reference
Dimensions
Width - 97cm
Depth - 202cm
Height - 91cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
Issue 1 - 25/06/10
Advertisement
Related Manuals for Argos Dalton Metal 3ft Frame 656/9624
Summary of Contents for Argos Dalton Metal 3ft Frame 656/9624
- Page 1 Dalton Metal 3ft Frame Assembly Instructions 656/9624 - Please keep for future reference Dimensions Width - 97cm Depth - 202cm Height - 91cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800 Issue 1 - 25/06/10...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • As you unpack and prepare recommend the components and tools listed on for assembly, clear an area for use of power pages 2 and 3.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 6400800 Please check you have all the panels listed below Left footboard post Left headboard post Right headboard post (90.6 x 5cm) (53.1 x 5cm) (90.6 x 5cm) Right footboard post Top horizontal bar x 2...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 36mm Bolt x 24 42mm Bolt x 24 30mm Bolt x 8 Small plain washer x 48 Spring washer x 8...
- Page 5 Assembly Instructions Step 1 Assemble headboard Assemble top horizontal and middle horizontal bars to left headboard post right headboard post using bolts as shown in the figure. Note: Do not fully tighten bolts. Step 2 Assemble footboard Assemble top horizontal and middle horizontal bars to left...
- Page 6 Assembly Instructions Step 3 Assemble side rails Three people are needed here. Assemble side rails to headboard frame and footboard frame using bolts , spring washers and large plain washers Note:Do not fully tighten bolts. Step 4 Assemble slats Assemble slats to the unit using bolts , small...
- Page 7 Dalton 3ft Frame Assembly Instructions 656/9624 - Please keep for future reference 758/4859 Dimensions Width - 94.4cm Depth - 202cm Height - 90.6cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800 Issue 1 - 25/06/10...
- Page 8 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • As you unpack and prepare recommend the components and tools listed on for assembly, clear an area for use of power pages 2 and 3.
- Page 9 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0845 6400800 Please check you have all the panels listed below Left footboard post Left headboard post Right headboard post (90.6 x 5cm) (53.1 x 5cm) (90.6 x 5cm) Right footboard post Top horizontal bar x 2...
- Page 10 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 36mm Bolt x 24 30mm Bolt x 8 Plain washer x 8 Spring washer x 8 Large hex key x 1...
- Page 11 Assembly Instructions Step 1 Assemble headboard Assemble top horizontal and middle horizontal bars to left headboard post right headboard post using bolts as shown in the figure. Note: Do not fully tighten bolts. Step 2 Assemble footboard Assemble top horizontal and middle horizontal bars to left...
- Page 12 Assembly Instructions Step 3 Assemble side rails Three people are needed here. Assemble side rails to headboard frame and footboard frame using bolts , spring washers and plain washers Note:Do not fully tighten bolts. Step 4 Assemble slats Insert slats to the side rails.
