Felix 2 Drawer Bedstead
Step 7
Assembly Instructions
Dimensions Double
Width x Depth x Height
145cm x 228cm x 92cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01992 450333
- Please keep for future reference
Dimensions King
Width x Depth x Height
160cm x 235cm x 92cm
697/1236
697/1195
697/1205
697/1243
697/1212
697/1250
Dimensions Super King
Width x Depth x Height
189cm x 235cm x 92cm
Issue 1 - 24.04.12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Felix 697/1236
Summary of Contents for Argos Felix 697/1236
- Page 1 Felix 2 Drawer Bedstead Step 7 Assembly Instructions 697/1236 - Please keep for future reference 697/1195 697/1205 697/1243 697/1212 697/1250 Dimensions Double Dimensions King Dimensions Super King Width x Depth x Height Width x Depth x Height Width x Depth x Height 145cm x 228cm x 92cm 160cm x 235cm x 92cm 189cm x 235cm x 92cm...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Assemble the item as close • Check you have all the • We do not components and tools listed on to its fi nal position (in the same recommend the pages 2 and 3.
- Page 3 Components If you have damaged or missing components, call the Customer Helpline: 01992 450333 Please check you have all the parts listed below 1 Right side rail 3 Headboard 2 Left side rail 5 Center Support Bar 4 Footboard Central slat caps x 13 (double) x 14 (king/super king) End slat caps...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Ø5/16 25mm Bolt x 8 Ø5/16 45mm Bolt x 6 M4 45mm Wood Screw x 8 M4 25mm Screw x 16...
- Page 5 Assembly Instructions Step 1 Attaching feet Attach 2 x wooden feet to the underside of the headboard using screws as shown. Repeat on the underside of the footboard Step 2 Align the long support with the pre-drilled holes on the centre rail .
- Page 6 Assembly Instructions Step 3 Attaching side rails a: Loosely fit bolts (A) to headboard before hooking the side rails Repeat this step for footboard b: Securely tighten bolts (A) once side rails have been attached. Do not over tighten.
- Page 7 Assembly Instructions Step 4 : Align the long support legs x 2 with the pre-drilled holes on the centre rail . Insert bolt and tighten using allen key. Step 5 : Insert 1/4 x 15mm screw into each side rail. bracket and clamp using M4 allen key.
- Page 8 Assembly Instructions Step 6 a: Insert the local centre L BRACKET rail in brackets on headboard footboard. BRACKET Step 7 Attaching Slats a: Insert slat into both sides of double plastic cap b: Insert single plastic onto ends of slat Repeat for all 14 pairs of slat.
- Page 9 Assembly Instructions Step 8 a: Align side panel to back panel front panel . Secure using screw b: Align bottom panel and secure using screw c: Attach 5 x castor to drawer’s bottom panel using screw d: Align outer front panel to inner front panel...
- Page 10 Assembly Instructions Step 9 Repeat to fit each drawer. IMPORTANT:Now with the bed in its final position please check and fully tighten all fixings and bolts. Assembly is now complete.
