Foley 2 Door TV Unit
Assembly lnstructions - Please keep for future reference
Dimensions
Width - 120cm
Depth - 40cm
Height - 57cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
358/8914
Issue 1- 28-11-14
Advertisement
Related Manuals for Argos Foley 358/8914
Summary of Contents for Argos Foley 358/8914
- Page 1 Foley 2 Door TV Unit Assembly lnstructions - Please keep for future reference 358/8914 Dimensions Width - 120cm Depth - 40cm Height - 57cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1- 28-11-14...
- Page 2 Safety and Care Advice Assemble the item as close We do not Check you have all the recommend the components and tools listed on to its final position (in the same pages 2 and 3. use of power room) as possible. Remove all fittings from the drill/drivers for Assemble on a soft level...
-
Page 3: Components - Parts
Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 Top x 1 Side panel x 2 (120x40x1.5cm) (39x40x1.5cm) Divider (right) x 2 Door x 2 (39x38.5x1.5cm) (38.5x29.5x1.5cm) Fixed shelf x 1 Adjustable shelf x 2 (53.7x38.5x1.5cm) (37x30x1.2cm) Underside... -
Page 4: Tools Required
Components - Fittings 0345 6400 800 Locking nut x 16 Metal dowel x 16 Wooden dowel x 20 Shelf support pin x 8 Plastic bracket x 8 3 x 14mm screw x 24 M6 x 50mm Allen screw x 8 Spring washer x 8 Plain washer x 8 Door stop x 2... - Page 5 Assembly Instructions Preparing panels Place top panel base panel flat on the floor with the fixing holes facing up. Screw metal dowels into each panel as shown. Note: Screw metal dowels as far as shown. Do not overtighten. Insert wood dowels into panels shown.
- Page 6 Assembly Instructions Assembling panels Carefully lower the shelf assembly down onto top panel Insert locking nuts into dividers . Turn locking nuts clock wise to secure. Assemble side panels to top panel and secure using locking nuts Note: Ensure the grooves in side panels correctly aligned next to the groove in top panel...
- Page 7 Assembly Instructions Attaching base Carefully locate base panel into position as shown. Secure using locking nuts in side panels dividers Attaching legs Assemble legs to base panel using fixings...
- Page 8 Assembly Instructions Lccating shelves Fit shelf support pins the desired height. Carefully place adjustable shelves onto the support pins. Preparing doors Assemble hinges doors using screws Assemble doors side panels using screws...
- Page 9 Assembly Instructions Hinge adjustment To move doors up or down, loosen screws as shown and move doors to suit. Once doors are aligned, insert 2 more screws into the hinge plates and fully tighten all screws. To move doors in or out, loosen screw shown and move doors to suit.
- Page 10 Assembly Instructions Securing assembly Fit plastic brackets around the edge of back panel using screws If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW...
