Triple Metal And Polycotton Wardrobe
Assembly lnstructions - Please keep for future reference
Dimensions
Width - 147cm
Depth - 54cm
Height - 175cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts,call the Customer helpline： 0345 6400800
343/6004
356/0970
Issue 1-11/03/14
Advertisement
Table of Contents
Related Manuals for Argos Triple Metal And Polycotton Wardrobe
Summary of Contents for Argos Triple Metal And Polycotton Wardrobe
- Page 1 Triple Metal And Polycotton Wardrobe Assembly lnstructions - Please keep for future reference 343/6004 356/0970 Dimensions Width - 147cm Depth - 54cm Height - 175cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts,call the Customer helpline： 0345 6400800...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Assemble the unit as close to its components and tools listed on final position (in the same room) page 2. as possible. Warning: Assemble on a soft level surface cables.
- Page 3 Components - Parts If you need help or have damaged or missing parts,call the Customer helpline： 0345 6400800 Please check you have all the parts listed below Shelf x 1(67.5x53.4cm) Shelf x 2(40x54cm) Thin rods x 5(50cm) Thin rods x 2(82.4cm) Thin rods x 2(86.4cm) Thin rods x 24(28.2cm) Thin rods x 3(67.5cm)
- Page 4 Assembly Instructions Step 1 Note:It would be useful to ask someone to help you at this stage. a: Attach shelf into shelf as shown in the figure. Note: Make sure the shelf panel with yellow dot face upwards b: Insert vertical rods into shelf shown.
- Page 5 Assembly Instructions Step 2 a: Attach thin rods to shelf as shown in the figure. b: Insert thin rods into T-connector Attach assembled thin rods to thin rods c: Attach thin rods and hook Then insert the assembled unit into shelf...
- Page 6 Assembly Instructions Step 3 a: Attach assembled shelf to thin rod and thin rods shown in the figure. Then repeat step1c for the other two shelves assembly. b: Insert thin rods T-connector insert thin rods thin rods as shown in the figure. c: Insert thin rods to connector as shown...
- Page 7 Assembly Instructions Step 4 a: Attach assembled top frame to thin rod thin rods as shown 5 17 in the figure. b: Insert thin rods into hook c: Attach assembled hanging rod to thin rods as shown in the figure.
- Page 8 Assembly Instructions Step 5 a: Fitting the cover into assembled frame as shown in the figure. Note: It is recommen- ded that two people fit the cover to the frame. b: Fasten the ties at bottom.
- Page 9 Assembly Instructions Step 5 Fixing to wall wall It is recommended that the wardrobe is fixed to a wall. Note: Top panel The correct type of fixing must be used for your wall,seek professional advice if doubt. Mark the fixing hole on the wall and remove the wardrobe.
